Denzel RHV-1050-38-max [8/28] Rotary hammer

7

ROTARY HAMMER

EN

ATTENTION!

Before plugging in make sure the switch is in the "o" position. With long-term storage of the tool

the switch must be in the “o” position.

Power connection indicator 7 turns on when there is a supply voltage on the motor switches and indicates

that the machine is ready for operation. When the indicator is on, be careful; avoid pressing the switch key

unintentionally.

Before getting started you must:

• check the service ability of the used working tool;

• install the working tool, previously the shank of the working tool should be lubricated with special grease;

• if it is necessary use the dust collector supplied in the set. The dust collector is put on the tool shank before

premature wear o;

• when using a chisel establish a comfortable position of the working edge relative to the electrical rotary hammer

(the chisel should turn with the barrel without much eort). After adjusting the chisel position set the operation

mode switch 4 to , at the same time the barrel will be blocked from turning.

• using switch 4 set the required mode of work;

• try the Electrical Rotary Hammer by idling during 5-10 seconds (also after tool change).

While working:

• periodically remove the drill from the hole to remove sludge from the drilling zone;

• watch the condition of the tool and the working tool, their heating;

• provide the ecient cooling of Electrical Rotary Hammer and the disposal of processing products from the

treatment area, do not block the ventilation holes on the housing;

• protect the Electrical Rotary Hammer from exposure of intense heat sources and chemically active substances,

as well as from the ingress of liquids and solid objects inside the housing;

• avoid mechanical damage to the Electrical Rotary Hammer (shocks, falls, etc.);

working, let the Electrical Rotary Hammer work without load for 1-2 minutes for engine cooling, turn o the

engine and take a break until the gear housing become cool;
