8
CORDLESS DRILL
EN
OPERATION
Machine structure
The machine consists of a plastic body with a DC motor and a planetary gear located in it. The gearbox is equipped
with an adjustable mechanical clutch, providing a limitation of the maximum torque on the spindle. The body
goes into the handle in which the switch is installed. The lower part of the handle has a connector to attach the
battery.
LED light for working area is located above the switch in front, battery charge indicator is located above the switch
on the left (see pic. 1)
The machine is equipped with a hook 5 (pic. 1) for hanging to a belt or a pocket of working clothes. The hook is
xed with a screw to the body and can be installed both on the right and on the left side of the body.
Before using the tool, you must:
•
after transportation in winter conditions before turning on, withstand at room temperature until complete
drying of water condensate;
•
wipe the exterior of the machine with a cloth;
•
check the voltage of the charger. The voltage of the power supply must correspond to the value indicated on
the charger label;
•
x the workpiece;
•
check the compliance of the rated voltage of the machine to the rated voltage of the battery. Using a battery
with a higher rated voltage will damage the machine;
•
put on protective equipment (glasses, headphones, gloves) before starting work, put the tool in a comfortable
position, and take a steady posture;
•
try the machine idling (also after replacing drill bit or bit).
Install and remove battery
Before removing or installing the battery as well as before transporting and storing the machine set the direction
of rotation switch 4 (pic 1) in the middle position to avoid accidental switching on the machine.
ATTENTION!
Never connect batteries other than the original design or type to the tool. The use of batteries
not intended for this model of tool can lead to failure of both the tool and the battery.
Installation
Attach a charged battery to the tool moving it until click along the guides in the lower part of the handle. Make
sure the battery is rmly xed and not staggering.
Do not use excessive force when installing the battery. If the battery is not installed on the tool without much
eort, it may be a sign of damage or inconsistencies with this type or model of the tool.
Removal
To remove the battery, press the release button 7 (pic. 1) and slide the battery forward along the guides until it is
completely separated from the tool body.
Battery charge
ATTENTION!
The charger should only be connected to a single phase AC power network, the voltage of
which corresponds to the voltage indicated on the label.
