Plug the charger into a wall outlet. Insert the charger plug 15 (pic. 1) into the battery socket 12 (pic. 1). If the

battery is low or not fully charged, the red light indicator 13 (pic. 1) on the battery turns on, which indicates the

ongoing process of charging. Turning on of the green light indicator 11 (Pic. 1) on the battery indicates that the

charging process is over, the battery is charged.

ATTENTION!

Battery charging is possible at ambient temperatures from 0 °С to + 40 °С. DO NOT charge the

battery when the ambient temperature is negative.

NOTE. Remember to turn o the charger when charging is complete.

Your tool is equipped with a lithium-ion rechargeable battery which does not have memory eect. Batteries of

this type are rechargeable.

Keep the battery charged at a temperature not lower than 0 °С.

NOTE. New battery can reach its rated capacity after two or three charge-discharge cycles.

Battery charge level can be estimated using the indicator 9 (pic. 1), which turns on when you press the switch key.

Green color of the indicator is the evidence of sucient battery charge and availability, red - about the need to

charge the battery.

Reversal of rotation

ATTENTION!

The reversal of rotation must be done only when the engine is o. It is forbidden to switch the

direction of rotation while the machine is running.

The direction of rotation of the spindle is changed by the switch 4 (pic. 1). The switch has 3 xed positions. When

you press the switch on the right until it stops– right-hand spindle rotation is activated, when press to the left

- left-hand. Corresponding symbols are printed on the movable switch bar. The middle position of the switch

corresponds to the lock of the engine switch, at the same time, when you press the switch the power does not

move to the motor, and only the work area illumination and the residual battery indicator turn on.

Speed adjustment

The tool has the ability of the gradual change in the number of rotations of the working part.

The switch of the tool 8 (pic. 1) allows you to increase the speed of rotation from zero to maximum gradualy.

Rotational speed depends on the degree of pressure on the switch.

The machine is equipped with an electric spindle lock; it allows you to almost instantly stop the spindle when

you release the switch. Electric brake operation may be accompanied by a spark discharge visible through the

ventilation holes of the tool case. In this regard, the spark discharge in the tool engine, caused by abruptly

releasing the switch, is not a sign of any malfunction.

Switching speeds / modes

Switching is carried out using the switch 3 (pic. 1). The switch has two positions, indicated by numbers «1» and «2».

Position "1" corresponds to a lower speed of rotation of the chuck, this mode is designed for screwing and

unscrewing screws and other works, requiring the application of signicant torque. In this position of the switch

tool develops maximum torque.

Position "2" corresponds to the increased speed of rotation of the chuck; this mode is designed to perform the

most ecient drilling. The maximum torque at this position of the switch is less than at the position "1".

In case the switch 3 does not reach the end position, you need to bring it back, turn the machine on and o by

briey pressing the switch, perform a speed change after stopping the engine.
