ELECTRIC PLANER

Description

Electric planer is a plastic case where there is a collector AC motor. In the lower part of the case there are support

base plates made of aluminum alloy. The front base plate can move vertically, and it provides the adjustment of

the removal rate in a single pass (cutting depth). The blade roll of the planer is installed in the housing on rolling

bearings and is driven by a belt drive. The planer is equipped with an adjustable dust removing system, which

allows carrying out dust to the right or left side. The back  xed base plate is  tted with a thrust bearing protecting

the blades and the surface from damage. The engine is controlled by a switch located in the main handle.

The machine is equipped with non-sharpened replaceable double-side blades  xed in a blade roll. A key, stored in

a holder located in the back of the case, is used to remove and install blades.

OPERATION

ATTENTION!

Always disconnect the power cable from the electrical outlet before preparing for the

operation, adjustment, maintenance of the power tool.

ATTENTION!

After transporting in winter conditions, before switching on, the machine must be kept at room

temperature until the condensate is completely dry.

1. Plane assembly

The plane is supplied assembled with installed and adjusted blades. There is no need to adjust the factory-installed

blades. Position adjustment screws 16 (pic. 1) are  xed at the factory with paint.

If necessary, install the edge guide to the tool. To do this unscrew the screw  xing the guide 11 (pic. 1), install the

guide into the groove of the housing and  x it with a screw, screwing it into place.

To maintain cleanliness in the workplace it is recommended to use a supplied dust bag. The nozzle of the bag with

a little tightness is connected with a pipe on the right or left side. At the same time, it is necessary to switch the

direction of dust removing to the corresponding direction using switch 3 (pic. 1).

2. Adjustment of the cutting depth in a single pass

To adjust the cutting depth in a single pass turn the front handle of the planer 1 (pic. 1) around its axis. Focus on

the scale applied to the bottom of the handle. For coarser and faster pcutting use a cutting depth of 1..2 mm, for

 nishing use it up to 1 mm.

3. Power connection

ATTENTION!

Before power connection, ensure the integrity of the product, no external damage. Pay special

attention to the reliability of the mounting of blades in the roll, the tightening of the screws

 xing the blades 15 (pic. 1). Make sure the power

switch is in the “o ” position.

ATTENTION!

The electric tools should be connected only to the single phase AC which voltage corresponds

to the voltage indicated on the table of characteristics placed on the tool. If the rating plate

indicates voltage of 230V, then the power tool can also be switched on

to a chain with voltage

of 220 V.
