6 BRIGGSandSTRATTON.com
H. Stop Switch (if equipped)
I. Fuel Tank and Cap
J. Oil Drain Plug
K. Dipstick
L. Muffler, Muffler Guard, Spark Arrester (if equipped), Muffler Deflector (if equipped)
M. Fuel Shut-off
N. Carburetor
O. Spark Plug
P. Fuel Filter (if equipped)
Engine Control Symbols and Meanings
Symbol Meaning Symbol Meaning
Engine speed - FAST Engine speed - SLOW
Engine speed - STOP ON - OFF
Engine start - Choke
CLOSED
Engine start - Choke OPEN
Fuel Cap
Fuel Shut-off - OPEN
Fuel Shut-off - CLOSED
Fuel level - Maximum
Do not overfill
Operation
Oil Recommendations
Oil Capacity:See theSpecificationssection.
NOTICE
This engine was shipped from Briggs & Stratton without oil. Equipment manufacturers
or dealers may have added oil to the engine. Before you start the engine for the first
time, make sure to check the oil level and add oil according to the instructions in this
manual. If you start the engine without oil, it will be damaged beyond repair and will
not be covered under warranty.
We recommend the use of Briggs & Stratton
®
Warranty Certified oils for best
performance. Other high-quality detergent oils are acceptable if classified for service SF,
SG, SH, SJ or higher. Do not use special additives.
Outdoor temperatures determine the correct oil viscosity for the engine. Use the chart
to select the best viscosity for the outdoor temperature range expected. Engines on
most outdoor power equipment operate well with 5W-30 Synthetic oil. For equipment
operated in hot temperatures, Vanguard
®
15W-50 Synthetic oil provides the best
protection.
A SAE 30 -Below 40 °F (4 °C) the use of SAE 30 will result in hard starting.
B 10W-30 -Above 80 °F (27 °C) the use of 10W-30 may cause increased oil
consumption. Check oil level more frequently.
C 5W-30
D Synthetic 5W-30
E
Vanguard
®
Synthetic 15W-50
Check Oil Level
See Figure: 5
Before adding or checking the oil
• Make sure the engine is level.
• Clean the oil fill area of any debris.
1. Remove the dipstick (A, Figure 5) and wipe with a clean cloth.
2. Install the dipstick (A, Figure 5). Do not turn or tighten.
3. Remove the dipstick and check the oil level. Correct oil level is at the top of the full
indicator (B, Figure 5) on the dipstick.
4. If oil level is low, slowly add oil into the engine oil fill (C, Figure 5). Fill to point of
overflowing.
5. Reinstall and tighten the dipstick (A, Figure 5).
Low Oil Protection System (if equipped)
Some engines are equipped with a low oil sensor. If the oil is low, the sensor will either
activate a warning light or stop the engine. Stop the engine and follow these steps
before restarting the engine.
• Make sure the engine is level.
• Check the oil level. See the Check Oil Level section.
• If the oil level is low, add the proper amount of oil. Start the engine and make sure
the warning light (if equipped) is not activated.
• If the oil level is not low, do not start the engine. Contact a Briggs & Stratton
Authorized Service Dealer to have the oil problem corrected.
Fuel Recommendations
Fuel must meet these requirements:
• Clean, fresh, unleaded gasoline.
• A minimum of 87 octane/87 AKI (91 RON). High altitude use, see below.
• Gasoline with up to 10% ethanol (gasohol) is acceptable.
NOTICE Do not use unapproved gasolines, such as E15 and E85. Do not mix oil in
gasoline or modify the engine to run on alternate fuels. Use of unapproved fuels will
damage the engine components, which will not be covered under warranty.
To protect the fuel system from gum formation, mix a fuel stabilizer into the fuel.
SeeStorage.All fuel is not the same. If starting or performance problems occur,
change fuel providers or change brands. This engine is certified to operate on gasoline.
The emissions control system for this engine is EM (Engine Modifications).
High Altitude
At altitudes over 5,000 feet (1524 meters), a minimum 85 octane/85 AKI (89 RON)
gasoline is acceptable.
For carbureted engines, high altitude adjustment is required to maintain performance.
Operation without this adjustment will cause decreased performance, increased fuel
consumption, and increased emissions. Contact a Briggs & Stratton Authorized Service
Dealer for high altitude adjustment information. Operation of the engine at altitudes
below 2,500 feet (762 meters) with the high altitude adjustment is not recommended.
