14
adjustment features of this router table enable a
high degree of accuracy. Other router tables are
included in the accessories programme.
a) Large surface router table
• Slide the router table onto the retaining pin on
the machine.
• Tighten the screw [4-1] to clamp the router table
in position.
• Place the extraction hood [4-2] in position.
• Tighten the screw [4-3] to clamp the extraction
hood in position.
• Place the extractor connector [4-4] on the ex-
traction hood.
Removal is performed in reverse sequence to
installation.
b) Router table for edge veneer
The "router table for edge veneer" (only in SET
scope of delivery) is designed for fl ush trimming
veneer overhang and profi le routing.
fThe router table is tilted 1.5° so that the surface
coating is not damaged during edge routing. A
router table with 0° inclination angle for precise
cuts is available as an accessory.
• Secure the sensor [5-1] to the machine using
the preassembled screws. Slide the sensor in
the long holes to adjust the routing tool to the
perfect position.
• Slide the router table onto the retaining pin on
the machine.
• Tighten the screw [5-2] to clamp the router table
in position.
• Place the extraction hood [5-3] in position.
• Tighten the screw [5-4] to clamp the extraction
hood in position.
Removal is performed in reverse sequence to
installation.
7.3 Changing the routing tool
WARNING
Risk of accident - the routing tool may be hot
after use and has sharp edges.
• Allow the tool to cool before changing.
• Wear protective gloves when changing tools.
• Remove the router table before changing the
routing tool.
a) Removing the tool
• Press the spindle lock [6-1].
• Unscrew the locking nut [6-2] using the open-
end wrench (size 19) until you are able to remove
the tool.
• Release the spindle lock [6-1].
b) Inserting the tool
• Insert the routing tool [6-3] into the open
clamping collet as far as possible, but at least
up to the mark (
) on the shank.
• Press the spindle lock [6-1].
• Tighten the locking nut [6-2] using the open-end
wrench (size 19).
• Release the spindle lock [6-1].
7.4 Changing the clamping collet
Only compatible tools can be used in combina-
tion with the clamping collets supplied. 8 mm,
6 mm and 1/4" (6.35 mm) clamping collets can
be used.
• Press the spindle lock [7-1].
• Unscrew the locking nut [7-2] completely.
• Release the spindle lock [7-1].
• Remove the locking nut from the spindle to-
gether with the clamping collet [7-3]. Do not
separate the locking nut and clamping collet
as these form a single component.
• Attach a different clamping collet with locking
nut to the spindle.
• Screw on the locking nut loosely. Do not tighten
the locking nut until a router bit is inserted.
7.5 Adjusting the routing depth
• Unscrew the rotary knob [8-3] and the clamp
[8-1] (large surface router table only).
• Turn the rotary wheel [8-2] to set the router table
to the required routing depth.
• Tighten the rotary knob [8-3] and the clamp [8-1]
(large surface router table only).
7.6 Dust extraction
CAUTION
Dust may be harmful or cause allergic reac-
tions!
• Always connect the machine to a dust extractor.
• When performing work that generates dust,
always wear a dust mask.
Extraction hoods are supplied for both router
tables; a Festool extractor (extractor hose with
a diameter of 27 mm) can be connected to these
extraction hoods.
The dust extractor (extractor hose with dia.
27 mm) can also be attached to the large surface
router table or the side stop depending on the
application.
