Festool MFK 700 EQ-Set 574284 [15/92] Warning

8 Working with the machine

WARNING

Risk of injury

• Hold the machine with both hands.

• Always secure the workpiece in such a manner

that it cannot move while being routed.

fGuide the machine along the workpiece at a

steady rate of advance.

8.1 Machine guidance methods

a) Routing with side stop

The side stop is positioned parallel to the work-

piece edge.

The side stop can only be ﬁ tted to the large sur-

face router table without a ﬁ tted extraction hood

[4-2].

• Insert the fine adjuster [9-3] into the side

stop.

• Secure both guide rods [9-5] with the two rotary

knobs [9-2] on the side stop.

• Insert the side stop into the grooves on the rout-

er table to the required distance and secure the

guide rods by turning the rotary knob [9-1].

Rough adjustment

• Loosen the screws [9-2] and [9-4] and slide the

side stop.

• Tighten the screws.

Fine adjustment

• Loosen the screws [9-2] and turn the green

wheel on the ﬁ ne adjuster [9-3].

fThe distance between each line on the rotary

wheel is 0.1 mm - one full turn of the ring rep-

resents 1 mm.

• Tighten the screws [9-2].

b) Edge trimming with bearing guide [Fig.

10]

Use routing tools with a bearing guide in the

machine when edge trimming with the large

surface router table. The machine is then guided

in such a way that the bearing guide rolls off the

workpiece.

When trimming edges, always use the extraction

hood [10-1] for improved dust extraction.

c) Edge trimming with sensor and router ta-

ble for edge veneer [Fig. 11]

When edge trimming with the router table for

edge veneer (only in SET scope of delivery), ﬁ t the

sensor [11-1] to the machine (see Chapter 7.2 b).

The machine is then guided in such a way that the

sensor rests against the workpiece.

8.2 Aluminium processing

WARNING

Risk of accident - always perform the following

safety measures when routing aluminium:

• Add a residual-current circuit-breaker (FI,

PRCD).

• Connect the machine to a suitable dust ex-

tractor.

• Remove dust deposits from the motor housing

on a regular basis.

• Wear protective goggles.

9 Service and maintenance

WARNING

Risk of accident, electric shock

• Always pull the plug out of the socket before

performing any type of work on the ma-

chine.

• All maintenance and repair work which re-

quires the motor housing to be opened must

only be carried out by an authorised service

workshop.

• Check the plug and the cable regularly and

should either become damaged, have them

replaced by an authorised after-sales service

workshop.

• To ensure constant air circulation, always keep

the air vent slits in the motor housing clean and

free of blockages.

The machine is equipped with self-disconnecting

special carbon brushes. If they are worn, power is

interrupted automatically and the machine comes

to a standstill.

10 Accessories, tools

Use only original Festool accessories and Festool

consumable material intended for this machine

because these components are designed spe-

ciﬁ cally for the machine. Using accessories and

consumable material from other suppliers will

most likely affect the quality of your working

results and limit any warranty claims. Machine

wear or your own personal workload may increase

depending on the application. Protect yourself and

your machine, and preserve your warranty claims

by always using original Festool accessories and

Festool consumable material!
