ENGLISH en

Fig. A

1 Keyless chuck

2 Sleeve (torque, drilling, impact drilling)*

witch (1st/2nd gear)

4 Rotation selector switch (rotation setting,

transport lock) - both sides of the machine

5Bit depot *

6Belt hook *

attery pack release button

8 Capacity indicator button

9 Capacity and signal indicator

Battery pack

11 LED lights

12 Trigger switch

*equipment-specific

7.1 Battery pack, capacity and signal display

Fig. B

Charge the battery pack before use.

If performance diminishes, recharge the battery

pack.

The ideal storage temperature is between 10°C and

30°C.

7.2 Removing, replacing battery pack

Fig. C

7.3 Setting direction of rotation, transporting

safety device (switch-on lock) Fig. D

7.4 Selecting gear stage Fig. E

Do not set the switch (3) unless the motor has

stopped completely!

7.5 Setting torque limitation,

drilling, impact drilling Fig. F

7.6 Switching on/off, setting speed

Fig. A

Switching on, speed: press the trigger (12). The

speed can be changed by pressing in the

trigger.

Switching off: release the trigger (12). Note:

The

noise that the machine makes when it switches

off is due to the design (quick stop) and has no

influence on the function or the service life of

the machine.

7.7 Keyless chuck Fig. G

With a soft tool shank, retightening may be required

after a short period of operation.

Notes on

machines with the designation SB...

1. The ratchet sound which can possibly be heard

after opening the drill chuck is functional and is

switched off by a reverse rotation of the sleeve.

2. Clamping tool:

Turn sleeve in direction "GRIP, ZU" until the

noticeable mechanical resistance has been

overcome.

Caution! The chuck is not yet fully tight-

ened! Keep turning the sleeve (it must "click"

when turning)) until it cannot be turned any

further - only now is the tool safely clamped.

Cleaning: From time to time, hold the machine

vertically with the keyless chuck facing

downwards and turn the sleeve fully in direction

"GRIP, ZU" and then turn fully in direction

"AUF, RELEASE". The dust collected falls from

the keyless chuck.

7.8 Unscrewing chuck Fig. H

Employ the same procedure when attaching the

chuck, except in reverse order.

7.9 Chuck with quick bit change system (for

BS 14.4 LT Quick, BS 18 LT Quick)

Fig. I

To remove: Push the interlock ring forward (a),

advance and pull off the chuck (b).

To mount: Push the interlock ring forward and

move the chuck as far as the limit stop on the drill

spindle.

7.10 Attaching the belt hook (depending on

machine features)/bit depot (depending

on machine features) Fig. J

Attach the belt hook to the left (6), as shown.

Attach the bit depot to the right (5), as shown.

8.1

The machine's multifunctional monitoring

system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode. A warning signal sounds (contin-

uous beeping). The beeping stops after a maximum

of 30 seconds or when the trigger (12) is released.

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1. Battery pack almost empty Fig. A, B (The

electronics protect the battery pack against

damage through total discharge).

If one LED is flashing (9), the battery pack is

almost flat. If necessary, press the (8) button

and check the LEDs (9) to see the charge level.

If the battery pack is almost flat, it must be

recharged.

2. Long continuous overloading of the machine will

activate the temperature cut-out.

Leave the machine or battery pack to cool.

Note:

If the battery pack feels very warm, the

pack will cool more quickly in an "AIR COOLED"

charger.

6. Overview

7. Use

8. Troubleshooting
