5
ENGLISH
(Original instructions)
d. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tools
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
@
Warning! Additional safety warnings for oscil-
lating tools
u Hold power tool by insulated gripping surfaces when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting ac-
cessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator
an electric shock
u Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by hand or against your body leaves it unstable and
may lead to loss of control.
@
Warning! Contact with or inhalation of dusts
arising from sanding applications may endanger
the health of the operator and possible bystand-
ers. Wear a dust mask specically designed for
protection against dust and fumes and ensure
that persons within or entering the work area are
also protected.
u Thoroughly remove all dust after sanding.
u Take special care when sanding paint which is possibly
lead based or when sanding some woods and metal which
may produce toxic dust:
t Do not let children or pregnant women enter the work
area.
t Do not eat, drink or smoke in the work area.
t Dispose of dust particles and any other debris safely.
u The intended use is described in this instruction manual.
The use of any accessory or attachment or performance
of any operation with this tool other than those recom-
mended in this instruction manual may present a risk of
personal injury and/or damage to property.
u The accessory will continue to move after releasing the
switch. Always switch the tool off and wait for the acces-
sory to come to a complete standstill before putting the
tool down.
u Keep hands away from cutting area. Never reach
underneath the work piece for any reason. Do not insert
ngers or thumb into the vicinity of the reciprocating blade
and blade clamp. Do not stabilize the saw by gripping the
shoe.
u Keep blades sharp. Dull or damaged blades may cause
the saw to swerve or stall under pressure. Always use the
appropriate type of saw blade for the workpiece material
and type of cut.
u When cutting pipe or conduit, make sure that they are free
from water, electrical wiring, etc.
u Do not touch the workpiece or the blade immediately after
operating the tool. They can become very hot.
u Be aware of hidden hazards, before cutting into walls,
oors or ceilings, check for the location of wiring and
pipes.
Safety of others
u This appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concern-
ing use of the appliance by a person responsible for their
safety.
u Children should be supervised to ensure that they do not
play with the appliance.
Residual risks.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
u Injuries caused by touching any rotating/moving parts.
u Injuries caused when changing any parts, blades or ac-
cessories.
u Injuries caused by prolonged use of a tool. When using
any tool for prolonged periods ensure you take regular
breaks.
u Impairment of hearing.
u Health hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially
oak, beech and MDF.)
