English
Recommended accessories
Do not draw up the fastening elements
DWT
too tight to avoid damaging the thread.
You can find the recommended DWT accessories on
Mounting / dismounting / setting-up of
the page 38-54 of the instruction. The bright range of the
some elements is the same for all power
accessories will allow you to perform necessary kinds of
tool models, in this case specific models
works effectively.
are not indicated in the illustration.
DWT
Additional handle (see fig. 1)
power tool designation
Always use the additional handle 4 when operating.
Power tools allow the following types of work to be
Additional handle 4 may be positioned as deemed
performed:
comfortable by the user.
·
drilling without impact (in wood, synthetic materials,
• Loose additional handle 4 as shown in fig. 1.
metal);
• Place additional handle 4 in desired position.
·
impact drilling (in brick, concrete, natural stone);
• Tighten additional handle 4 as shown in fig. 1.
·
chiseling works (slotting cable channels in brick,
concrete, stone, removing old tiles, etc.);
Depth stop (see fig. 2)
·
loosening and tightening threaded fasteners.
Use depth stop 6 to set a required drilling depth (see
fig. 2).
Safety guidelines during
• Press and hold retainer 5.
power tool operation
• Move depth stop 6 to set a required drilling depth.
• Release retainer 5.
• Avoid stopping an electric tool motor when loaded.
• Maintain a stable position while working, hold the
Mounting / replacement of accessories (see fig. 3)
electric tool with two hands.
• Never remove any chips or fragments with your
Borers DWT PLUS are able, due to the
electric tool's motor running.
designed features of the chuck DWT PLUS,
• Before starting work, make sure where hidden
to travel freely to some extent. This causes
electric cables and water and gas pipes are situated.
radial run-out at idle running that will be
Damaging the electric supply wiring or engineering
automatically centred during the drilling. It doesn't make
communications may cause a severe harm to the
any impact on the precision of bore drilling.
operator's life and health.
Before installing the borer (chisel), clean it and
If the working schedule cannot exclude damaging the
•
•
lubricate the shank with a thin layer of oil.
main supply cables, they have to be de-energized.
• Move fixing bush 3 back and hold it in this position
• When working, follow the position of the power
(see fig. 3).
supply cable. Avoid winding it around your legs or arms.
• When mounting, insert (slightly twisting) the borer
• Use only sharp and flawless borers and chisels, it will
(chisel) into the chuck 1 (DWT PLUS) against stop.
make operating the electric tool easier.
When removing, extract the borer (chisel) from the
• Never change the borer and chisel design or use
chuck 1 (DWT PLUS).
attachments and appliances, which are not
• Release fixing bush 3.
recommended for your electric tool.
• Test the borer (chisel) fixing by trying to remove it
• When working, never press the electric tool too hard,
from chuck 1 (DWT PLUS).
as this might lead to the borer or chisel seizing and
motor overloading.
Gloves are to be used when removing the
• Avoid the drill, borer and chisel seizing in the
borer (chisel) from chuck 1 (DWT PLUS),
material worked in. If this happens, do not try to
as the borer (chisel) may be dangerously
release them with your perforator's motor. It may
hot after long drilling.
damage the motor.
Replacing the dust protection casing (see fig. 4)
• Never force out the drills, borers or chisels stuck in
the material you are working on with a hammer or other
Dust protection casing 2 prevents the dust
objects the chipped off metal particles may harm both
from entering the DWT PLUS chuck. Never
the operator and the persons who are nearby.
use your power tool with a damaged dust
• Avoid overheating your electric tool, when using it for
protection casing 2 - if damaged, it must
a long time.
be immediately replaced. You can either do it on
• Never use a chisel to drill holes.
your own, or contact the DWT service center.
Installation and regulation
• Move fixing bush 3 back and hold it in that position
of power tool elements
(see fig. 4).
• Pull dust protection casing 2, and remove it.
Before carrying out any works on the power tool it
• Install a new dust protection casing 2.
3
must be disconnected from the mains.
• Release fixing bush .
9
