13
English
Noise
information
Always wear ear protection if the sound
pressure exceed 85 dB(A).
Declaration of
conformity
We declare under our sole responsibility that the
product described under "Power tool specications"
is in conformity with all relevant provisions of the di-
rectives 2006/42/EC including their amendments and
complies with the following standards:
EN 55014-1:2006/+A1:2009/+A2:2011,
EN 55014-2:1997/+A1:2001/+A2:2008,
EN 61000-3-2:2006/+A1:2009/+A2:2009,
EN 61000-3-3:2013�
Certication Wu Cunzhen
manager
* - for power tools with voltage 220-230 V�
Merit Link International AG
Stabio, Switzerland, 25�09�2020
General
safety rules
WARNING - To reduce the risk of injury,
user must read instruction manual!
WARNING! Read all safety warnings and
all instructions. Failure to follow the warn-
ings and instructions may result in electric
shock, re and / or serious injury.
Save all warnings and instructions for future refer-
ence.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operat-
ed (cordless) power tool�
Work area safety
• Keep work area clean and well lit. Cluttered or
dark areas invite accidents�
• Do not operate power tools in explosive atmos-
pheres, such as in the presence of ammable liq-
Power tool specications
Impact wrench SS06-22 SS06-24
Power tool code
[110-127 V ~50/60 Hz]
[220-230 V ~50/60 Hz]
see page 7
Rated power [W] 600 600
Power output [W] 320 320
Amperage at voltage
110-127 V [A]
220-230 V [A]
6
3
6
3
No-load speed [min
-1
] 1900 1700
Torque [Nm] 150-300 450-500
Impact rate [min
-1
] 2600 2400
Min. diameter of screws
[mm]
[inches]
M14 M18
Max. diameter of screws
[mm]
[inches]
M22 M24
Tool holder type
[mm]
[inches]
12,7 x 12,7
1/2" x 1/2"
19 x 19
3/4" x 3/4"
Weight
[kg]
[lb]
3,65
8�05
5,3
11�69
Safety class
Sound pressure [dB(A)] — —
Acoustic power [dB(A)]
— —
Weighted vibration [m/s
2
] — —
