16
English
Symbol Meaning
Do not dispose of the power
tool in a domestic waste
container�
DWT
power tool designation
The power tool is intended for tightening and loosing
nuts and bolts�
The area of the tool application can be expanded due
to use of additional accessories�
1
Power tool
components
On / off switch (reverse function)
2 Body
3 Tool holder
4 Ventilation slots
5 Additional handle *
6 Pin *
7 Socket wrench *
8 Retainer ring (rubber) *
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation
of power tool elements
Before carrying out any works on the power tool it
must be disconnected from the mains.
Socket wrench mounting / dismounting (see g. 1)
• While mounting, install the socket wrench 7 on the
tool holder 2 as shown on the gure 1.
• Disassembly operations do in reverse sequence�
Additional handle (see g. 2)
[SS06-24]
Always use the additional handle 5 when operating�
Additional handle 5 may be positioned as deemed
comfortable by the user�
• Loose additional handle 5 as shown in g. 2.1.
• Place additional handle 5 in desired position (see
g. 2.2).
• Tighten additional handle 5 as shown in g. 2.3.
Initial operating
of the power tool
Always use the correct supply voltage: The power sup-
ply voltage must match the information quoted on the
power tool identication plate.
Switching the power
tool on / off
Rotation to the right
Press and hold the on / off switch 1 on the bottom ("F",
see g. 3), to switch off - release it.
Rotation to the left
Press and hold the on / off switch 1 on the top ("R", see
g. 4), to switch off - release it.
Design features
of the power tool
The tool holder 2 with the socket wrench 7 is driven
by an electric motor via a gear and impact mecha-
nism�
The working procedure is divided into two phases:
Screwing in and tightening (impact mechanism in ac-
tion)� The impact mechanism is activated as soon as
the screwed connection runs tight and thus load is
put on the motor, converting the power of the motor
to steady rotary impacts� When loosening screws or
nuts, the process is reversed�
The torque depends on the impact duration� The
maximum achieved torque results from the sum of
all individual torques achieved through impact� The
maximum torque is achieved after an impact dura-
tion of 3-5 seconds� After this duration, the tighten-
ing torque is increased only minimally� However, the
transmission housingheats up noticeably�
The consequences of excessive heating-
up are high wear of all hammer mechanism
components and a high requirement of lu-
bricant.
The impact duration is to be determined for each re-
quired tightening torque� The actually achieved tight-
ening torque is always to be checked with a torque
wrench�
Recommendations
on the power tool operation
Apply the socket wrench to the tool hold-
er only when the power tool it is switched
off.
A torque depends on the following factors:
• Strength properties of the screws / nuts�
• Type of backing (washer, disc spring, seal)�
• Strength properties of the material being screwed /
bolted together�
• Lubrication conditions at the screw / bolt connec-
tion�
Hard seat - is given for metal-to-metal screw applica-
tions with the use of washers� After a relatively short
impact duration, the maximum torque is reached� Un-
necessary long impact duration only causes damage
to the machine�
