6 ENGLISH
Hook
CAUTION: Always be sure that the tool is
switched off and unplugged when hanging the
tool.
CAUTION: Never hang the tool at high or
potentially unstable location.
CAUTION: Do not hook the tool on your belt
or other accessories. The recipro saw blade may
contactyourbodyandcausepersonalinjury.
►Fig.4: 1. Hook
The hook is convenient for hanging the tool temporarily.
To use the hook, simply lift up hook until it snaps into
the open position.
When not in use, always lower hook until it snaps into
the closed position.
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and unplugged before carrying out
any work on the tool.
Installing or removing the recipro
saw blade
CAUTION: Always clean out all chips or for-
eign matter adhering to the blade and around the
blade clamp.Failuretodosomaycauseinsufcient
tighteningoftheblade,resultinginaseriousinjury.
To install the recipro saw blade, always make sure that
the blade clamp lever (part of the blade clamp sleeve)
is in released position on the insulation cover before
inserting the recipro saw blade. If the blade clamp lever
isinxedposition,rotatethebladeclampleverinthe
direction of the arrow so that it can be locked at the
released positon .
►Fig.5: 1. Blade clamp lever 2. Released position
3. Fixed position
Insert the recipro saw blade into the blade clamp as far
asitwillgo.Thebladeclampsleeverotatesandxes
the recipro saw blade. Make sure that the recipro saw
blade cannot be extracted even though you try to pull
it out.
►Fig.6: 1. Recipro saw blade 2. Blade clamp sleeve
CAUTION: If you do not insert the recipro saw
blade deep enough, the recipro saw blade may be
ejected unexpectedly during operation. This can
be extremely dangerous.
To remove the recipro saw blade, rotate the blade
clamp lever in the direction of the arrow fully. The reci-
pro saw blade is removed and the blade clamp lever is
xedatthereleasedposition .
►Fig.7: 1. Recipro saw blade 2. Blade clamp lever
CAUTION: Keep hands and ngers away from
the lever during the switching operation. Failure
to do so may cause personal injuries.
NOTE: If you remove the recipro saw blade without
rotating the blade clamp lever fully, the lever may not
be locked in the released position . In this case,
rotate the blade clamp lever fully again, then make
sure that the blade clamp lever locked at the released
position .
NOTE: If the blade clamp lever is positioned inside
thetool,switchonthetooljustasecondtoletthe
blade out. Unplug the tool before installing or remov-
ing the recipro saw blade.
OPERATION
CAUTION: Always hold the tool rmly with
one hand on insulation cover and the other on the
switch handle.
CAUTION: Always press the shoe rmly
against the workpiece during operation. If the
shoe is removed or held away from the workpiece
during operation, strong vibration and/or twisting will
be produced, causing the blade to snap dangerously.
CAUTION: Always wear gloves to protect
your hands from hot ying chips when cutting
metal.
CAUTION: Be sure to always wear suitable
eye protection which conforms with current
national standards.
CAUTION: Always use a suitable coolant
(cutting oil) when cutting metal. Failure to do so will
cause premature blade wear.
CAUTION: Do not quirk the blade during
cutting.
Presstheshoermlyagainsttheworkpiece.Donot
allow the tool to bounce. Bring the recipro saw blade
into light contact with the workpiece. First, make a pilot
groove using a slower speed. Then use a faster speed
to continue cutting.
►Fig.8
NOTICE: Do not cut the workpiece with the shoe
away from the workpiece or without the shoe.
Doing so increases the reaction force which may
break the recipro saw blade.
