Mounting and removing the wheel disc

(Fig. Aand D)

Do not use the machine without the

guard.

Only use sharp and undamaged wheel

discs.

• Always use suitable wheel disc for this

machine with diameter Ø 125 mm and abore

from 22.2 mm the thickness of the wheel disc

should be 6 mm for wheel disc for grinding and

3 mm for wheel disc for cutting, the mounting

wheel disc may not touch the safety guard.

Mounting

1. Place the machine on atable with the

protection guard (3) facing upwards.

2. Mount the flange (9) onto the spindle (7).

3. Place the wheel disc (10) onto the spindle (7).

4. Keep the spindle lock button (1) pressed and

firmly tighten the clamping nut (11) onto the

spindle (7) by using the spanner (12).

Removing

1. Place the machine on atable with the

protection guard (3) facing upwards.

2. Keep the spindle lock button (1) pressed and

loosen the clamping nut (11) using the spanner

(12).

3. Remove the wheel disc (10) from the spindle (7).

4. Keep the spindle lock button (1) pressed and

firmly tighten the clamping nut (11) using the

spanner (12).

Mounting the side handle (Fig. Aand G)

• The side handle (8) can be screwed into one of

the two side handle connection points (6).

4. OPERATION

Make sure that the work piece is properly

supported or fixed.

Switching on and off (Fig. B)

• To start the machine, press and hold the lockoff

button (2) and press the on/off switch (5).

• To stop the machine, release the on/off switch

(5).

• Hold the machine away from the work piece

when turning it on and off because the wheel

disc could damage the work piece.

• Clamp the work piece firmly or use another

method to ensure that it cannot move while

working.

• Check the discs regularly. Worn wheel

discs have anegative effect on the

machine’sefficiency. Change to anew wheel

disc in good time.

Deburring (Fig. H)

An angle of inclination of 30° to 40° will

give the best results when deburring.

Move the machine back and forth using

light pressure. This will prevent the work

piece from discolouring or becoming too

hot and will avoid making groves.

Never use abrasive cutting discs for

deburring work!

Cutting (Fig. I)

For cutting, aspecial protection guard

must be used (not included).

Maintain firm contact with the work piece to

prevent vibration and do not tilt or apply pressure

and when cutting. Use moderate pressure when

working, appropriate to the material that is being

worked on. Do not slow down wheel discs by

applying sideways counter pressure. The direction

in which you want to cut is important. The machine

must always work against the direction of the cut;

so never move the machine in the other direction!

There is the risk that the machine will catch in the

cut causing kickback and that you will lose control.

Hints for optimum use

• Clamp the work piece. Use aclamping device

for small work pieces.

• Hold the machine with both hands.

• Switch on the machine.

• Wait until the machine has reached full speed.

• Place the wheel disc on the work piece.

• Slowly move the machine along the work

piece, firmly pressing the wheel disc against

the work piece.

• Do not apply too much pressure on the

machine. Let the machine do the work.
