FERM ESM1014 без акк. и зу. [7/40] Description

Only use the following batteries of the FX-POWER

20V battery platform. Using any other batteries

could cause serious injury or damage the tool.

CDA1167 20V, 2Ah Lithium-Ion

CDA1168 20V, 4Ah Lithium-Ion

The following charger of the can be used to

charge these batteries.

CDA1169 Charger adapter

CDA1170 Quick charger

CDA1172 Quick charger

The batteries of the FX-POWER 20V battery

platform are interchangeable with all the FERM

FX-POWER battery platform tools.

Vibration level

The vibration emission level stated in this

instruction manual has been measured in

accordance with a standardised test given in

EN 62841; it may be used to compare one tool

with another and as a preliminary assessment of

exposure to vibration when using the tool for the

applications mentioned:

- using the tool for different applications, or with

different or poorly maintainted accessories,

may significantly increase the exposure level

- the times when the tool is switched off or when

it is running but not actually doing the job, may

significantly reduce the exposure level.

Protect yourself against the effects of vibration by

maintaining the tool and its accessories, keeping

your hands warm, and organizing your work

patterns.

Description

The numbers in the text refer to the diagrams on

page 2 and 3.

1. On/off switch

2. Dust bag

3. Speed adjustment wheel

4. Sanding pad

5A. Upper grip

5B. Lower grip

6. Dust extraction port

7. Battery unlock button

8. Battery (not included)

9. Sanding paper

10. Rubber ring

3. ASSEMBLY

Before any work on the power tool,

remove the battery.

The battery must be charged before first

use.

Inserting the battery into the machine (Fig. C)

Ensure that the exterior of the battery is

clean and dry before connecting to the

charger or machine.

1. Insert the battery (8) into the base of the

machine as shown in Fig. C.

2. Push the battery further forward until it clicks

into place.

Removing the battery from the machine (Fig. C)

1. Push the battery unlock button (7).

2. Pull the battery out of the machine like shown

in Fig. C.

Connecting the dust bag (Fig. D)

It is highly recommended to use the machine with

the dust bag (2), ensuring optimal dust collection.

• Slide the dust bag (2) onto the dust extraction

port (6) using a slight twisting motion.

• Keep sliding in twisting motion until the dust

bag (2) is positioned slightly over the rubber

ring (10), fixing it in place.

Note: The dust bag should be emptied when the

bag is half full to maintain optimal dust collection.

Mounting and removing the sanding paper

(Fig. B)

• Hold the machine on its side or upside down.

• Mount sanding paper (9) with the required grain

size onto the sanding pad (4). Make sure that the

perforation in the sanding paper (9) corresponds

with the perforation on the sanding pad (4).

• To remove the sanding paper (9), simply pull

the sanding paper from the sanding pad (4).

Note: Use coarse sanding paper for sanding

rough, uneven surfaces. Use medium sanding

paper for removing the remaining scratches from

the coarse sanding paper. Use fine sanding paper

for finishing surfaces.
