6 ENGLISH

FUNCTIONAL

DESCRIPTION

CAUTION: Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery

cartridge

CAUTION: Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION: Hold the tool and the battery car-

tridge rmly when installing or removing battery

cartridge.Failuretoholdthetoolandthebattery

cartridgermlymaycausethemtoslipoffyourhands

andresultindamagetothetoolandbatterycartridge

andapersonalinjury.

►Fig.1: 1. Red indicator 2.Button3. Battery cartridge

Toremovethebatterycartridge,slideitfromthetool

whileslidingthebuttononthefrontofthecartridge.

Toinstallthebatterycartridge,alignthetongueonthe

batterycartridgewiththegrooveinthehousingandslip

itintoplace.Insertitallthewayuntilitlocksinplace

withalittleclick.Ifyoucanseetheredindicatoronthe

uppersideofthebutton,itisnotlockedcompletely.

CAUTION: Always install the battery cartridge

fully until the red indicator cannot be seen.Ifnot,

itmayaccidentallyfalloutofthetool,causinginjuryto

youorsomeonearoundyou.

CAUTION: Do not install the battery cartridge

forcibly.Ifthecartridgedoesnotslideineasily,itis

notbeinginsertedcorrectly.

Indicating the remaining battery

capacity

Only for battery cartridges with "B" at the end of the

model number

►Fig.2: 1.Indicatorlamps2.Checkbutton

Pressthecheckbuttononthebatterycartridgetoindi-

catetheremainingbatterycapacity.Theindicatorlamps

lightupforfewseconds.

Indicator lamps Remaining

capacity

Lighted Off Blinking

75% to 100%

50% to 75%

25% to 50%

0% to 25%

Indicator lamps Remaining

capacity

Lighted Off Blinking

Charge the

battery.

Thebattery

may have

malfunctioned.

NOTE:Dependingontheconditionsofuseandthe

ambienttemperature,theindicationmaydifferslightly

fromtheactualcapacity.

Tool / battery protection system

Thetoolisequippedwithatool/batteryprotectionsys-

tem.Thissystemautomaticallycutsoffpowertothe

motortoextendtoolandbatterylife.Thetoolwillauto-

maticallystopduringoperationifthetoolorbatteryis

placedunderoneofthefollowingconditions:

Overload protection

Whenthetool/batteryisoperatedinamannerthat

causesittodrawanabnormallyhighcurrent,thetool

automaticallystopswithoutanyindication.Inthissit-

uation,turnthetooloffandstoptheapplicationthat

causedthetooltobecomeoverloaded.Thenturnthe

tool on to restart.

Overheat protection

Whenthetool/batteryisoverheated,thetoolstops

automatically.Inthissituation,letthetool/batterycool

beforeturningthetoolonagain.

Overdischarge protection

Whenthebatterycapacityisnotenough,thetoolstops

automatically.Inthiscase,removethebatteryfromthe

toolandchargethebattery.

NOTE:Overheatprotection(forbattery)willworkonly

withbatterieswithstarmarking.

►Fig.3: 1. Star marking

Switch action

►Fig.4: 1. Switch trigger

CAUTION: Before installing the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

Tostartthetool,simplypulltheswitchtrigger.Tool

speedisincreasedbyincreasingpressureontheswitch

trigger. Release the switch trigger to stop.

NOTE:Thetoolautomaticallystopsifyoukeeppull-

ingtheswitchtriggerforabout6minutes.

Lighting up the front lamp

►Fig.5: 1. Lamp
