5
ENGLISH
(Original instructions)
Electrical safety
This tool is double insulated; therefore no earth
wire is required. Always check that the power
supply corresponds to the voltage on the rating
plate.
• If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised STANLEY Service Centre
in order to avoid a hazard.
Using an extension cable
• Always use an approved extension cable suitable for the
power input of this tool (see technical data). Before use,
inspect the extension cable for signs of damage, wear
and ageing. Replace the extension cable if damaged or
defective. When using a cable reel, always unwind the
cable completely. Use of an extension cable not suitable
for the power input of the tool or which is damaged or
defective may result in a risk of fire and electric shock.
Features
This tool includes some or all of the following features.
1. Variable speed switch
2. Lock-on button
3. Forward/reverse slider
4. Chuck
5. Sleeve
6. Bit Shaft
7. Speed dial
8. Hole
9. Speed dial
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Keyed chuck (fig. B)
• Open the chuck by turning the sleeve (5)
counterclockwise.
• Insert the bit shaft (6) into the chuck.
• Insert the chuck key (7) into each hole (8) in the side of
the chuck and turn clockwise until tight.
Removing and refitting the chuck (fig. C)
• Open the chuck as far as possible.
• Remove the chuck retaining screw, located in the chuck,
by turning it clockwise using a screwdriver.
• Tighten an Allen key into the chuck and strike it with a
hammer as shown.
• Remove the Allen key.
• Remove the chuck by turning it counterclockwise.
• To refit the chuck, screw it onto the spindle and secure it
with the chuck retaining screw.
Use
Warning! Let the tool work at its own pace. Do not overload.
Warning! Before drilling into walls, floors or ceilings, check
for the location of wiring and pipes.
Selecting the direction of rotation (fig. D)
For drilling and for tightening screws, use forward
(clockwise) rotation. For loosening screws or removing a
jammed drill bit, use reverse (counterclockwise) rotation.
• To select forward rotation, push the forward/reverse
slider (3) to the left position.
• To select reverse rotation, push the forward/reverse
slider to the right.
Viewed when holding the drill in the operating position. After
any reversing operations, return slider (3) to forward
position.
Warning! Never change the direction of rotation while the
motor is running.
Switching on and off
• To switch the tool on, press the variable speed switch
(1). The tool speed depends on how far you press the
switch.
• For continuous operation, press the lock-on button (2)
and release the variable speed switch. This option is
available only at full speed.
• To switch the tool off, release the variable speed switch.
To switch the tool off when in continuous operation, press
the variable speed switch once more and release it.
• Based on the different applications, turn around the
speed dial (9) to control the maximum speed.
Proper Hand Position (fig.E)
Warning! To reduce the risk of serious personal
injury, ALWAYS use proper hand position as
shown in figure E.
