В. Основная чаша
В1. Чаша объемом 1,5 л.
В2. Крышка для чаши
В3. Толкатель
С. Комплект дисков
С 1. Диск для нарезания ломтиками
С2. Диск для нарезания стружкой
СЗ. Мелкая терка
С4. Средняя терка
С5. Крупная терка
Сб. Насадка для дисков
С7. Стержень для дисков.
D. Соковыжималка для цитрусовых.
D1. Фильтр
D2. Конус для цитрусовых
Е. Лопаточка
F. Комплект насадок
F 1. Пластмассовая насадка для замешивания теста
F 2. Нож для измельчения продуктов.
G. Блендер
G1. Мерный стаканчик
G2. Крышка емкости
G3. Емкость, объемом 1,5 л.
Н. Соковыжималка для фруктов и овощей
Н1. Толкатель
Н2. Крышка
НЗ. Фильтр
Н4. Емкость под выжимки
I. Насадка для взбивания крема
14
JUICE EXTRACTOR (Figure 9/10)
The juice extractor can be used to juice any kind of soft fruit or vegetable.
Place the bowl over the drive shaft, locate on motor base and rotate the
bowl anticlockwise until it locks into position place. (Figure 3)
Place the juice extractor assembly on to the shaft into the center of this
bowl ensuring central part is located over central drive shaft. Place juice
extractor lid on top of the bowl ensuring that it is placed over the three
locating slots at the top of the inside of the food processor bowl and
rotate anticlockwise until it locks into place. (Figure 9/10). Food needs to
be cut into suitable sizes, to insert into the filling tube before juicing. Peel
citrus fruits, pineapples, melons, etc. Stone cherries, plums, apricots,
peaches etc. Always switch on the appliance before you put the fruit or
vegetable in the juice extractor. Switch off the appliance from time to time
to remove pulp from the sieve and pulp collector bowl, if it starts to vibrate
strongly. Speed 2 is recommended. Do not use speed 3.
PRESSING/CITRUS PRESS (Figure 8)
Citrus Press is used for pressing the citrus fruits like lemons, oranges,
grapefruits. Place the bowl over the drive shaft locate on motor base and
rotate the bowl anticlockwise until it locks into position. (Figure 3) Place
the citrus press filter into the bowl with the into locking tab to the left of
the handle and turn the filter anticlockwise to slot the tab into the catch on
the handle. (Figure 8) Place the citrus cone onto the drive shaft. Slice cit\
rus fruit in half and place over the cone, hold down and turn processor
onto speed 1 until juice is extracted.
V. CLEANING AND MAINTENANCE
Always switch off and unplug the food processor after use and before
removing and cleaning attachments. Remove the bowl by turning clock\
wise. To make cleaning easier, rinse removable attachments straight after
use, after first removing. Wash and dry the attachments and bowls. Avoid
using scouring pads, harsh detergents and abrasives. Dry with a soft,
clean cloth. Wipe the motor base with a slightly damp cloth, do not
immerse in water. If your appliance does not work first check that the
appliance is plugged in correctly. Check that the parts are correctly posi\
tioned on the motor unit.
SERVICE LIFE OF THE FOOD PROCESSOR NOT LESS THAN 5 YEARS
11
ENGLISHРУССКИЙ
1607.qxd 05.06.03 15:37 Page 22
