27
OIMM – VENTUS PRO
PREVENT OF COMMON DANGERS AND RISKS
FILTER GRADE FILTER GRADE
INITIAL PRESSURE
DIFFERENTIAL
RECOMMENDED MAXIMUM
PRESSURE DIFFERENTIAL
Panel Filter
G-2
(65% ≤ Am ≤ 80%)
25 Pa 150 Pa
G-3
(80% ≤ Am ≤ 90%)
40 Pa 150 Pa
G-4
(90% ≤ Am)
50 Pa 150 Pa
Bag Filter
G-4
(90% ≤ Am)
65 Pa 150 Pa
M-5
(40% ≤ Em ≤ 60%)
55 Pa 250 Pa
M-6
(60% ≤ Em ≤ 80%)
60 Pa 250 Pa
F-7
(80% ≤ Em ≤ 90%);
0.4 μm - 35%
115 Pa 250 Pa
F-8 F8
(90% ≤ Em ≤ 95%);
0.4 μm - 55%
165 Pa 350 Pa
After opening the service door, the lters can be taken out by pulling aside.
Synthetic bag lter can be cleaned by vacuumed or compressed air besides can be washed with the sensitive
detergent and warm water.
Humidier should be cleaned regularly. The period changes according to the operating conditions, air
specications and water quality. During periodic maintenance of humidier, checks mentioned in its own manual
should be performed.
Sound attenuators can be taken out from the service door by unscrewing the components from the top and
bottom panels. Attenuators can be cleaned by vacuumed or compressed air.
HUMIDIFIER SECTIONS
SOUND ATTENUATORS
3.10.4
3.10.5
