VTS VENTUS PRO PVS 24x24 [30/34] Relubrication procedures
![VTS VENTUS PRO PVS 24x24 [30/34] Relubrication procedures](/views2/1893540/page30/bg1e.png)
29 30
OIMM – VENTUS PRO
Temperature correction factors kT (for lithium soap grease)
Temperature
of bearings (ºC )
70 70 80 90 100 110 120 130
Temperature
correction factor, kT
1 1 0.6 0.35 0.2 0.12 0.07 0.04
GREASE STRESS SURROUNDING FACTOR, kS
Low 0.8
Medium 0.5
High 0.2
! Surround factor kS considers in particular the external inuences such as humidity, shocks and vibrations
If the relubrication intervals are shorter than 6 months, then it is recommended that the grease ll in the bearing
arrangement be replenished at intervals corresponding to 0.5 times the relubrication intervals., the complete
grease ll should be replaced after three replenishment at the latest.
If the relubrication intervals are longer than 6 months it is recommended that all used grease be removed from
the bearing arrangement and replaced by fresh grease.
The 6 months limit represents a very rough guideline recommendation and may be adapted to particular
applications.
By adding small quantities of fresh grease intervals the used grease in the bearing arrangement will be partially
replaced.
Suitable quantities to be added are calculated by the following formula and are listed on following table.
G = 0.005 x D x B
G = Grease quantity to be added when replenishing (g) D = bearing outside diameter (mm)
B = total bearing width (mm)
RELUBRICATION PROCEDURES
REPLENISHMENT
3.10.8.1
3.10.8.2
Temperature correction factors kT (for lithium soap grease)
FRAME
CONTRUCTION
TYPE
FAN SIZE
250
280
315
355
400
450
500
560
630
710
700
900
1000
K
G d G d G d G d G d G d
3.9 25 5.6 30 6.8 35 8.4 40
9.9 50 13.2 60
Suitable quantities of intervals adding fresh grease (K2)
FRAME
CONTRUCTION
TYPE
FAN SIZE
560
630
710
800
900
1000
K2
G d G d G d
3.9 25 5.6 30 6.8 35
