VTS VENTUS PRO PVS PO 30 EC [14/16] Writing a group of output registers 0x10
![VTS VENTUS PRO PVS PO 30 EC [14/16] Writing a group of output registers 0x10](/views2/1893541/page14/bge.png)
VTS reserves the right to implement changes without prior notice.
www.vtsgroup.com Page 14 of 16 ver. 2.0 (11.2021)
Response format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x06
Register address
2
0x0000 – 0xFFFF
Value to be stored
2
0x0000 – 0xFFFF
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
Error format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x86
Error code
1
1 – 4
See section 4.2.4
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
4.2.3. Writing a group of output registers (0x10)
Command format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x10
Data block address
2
0x0000 – 0xFFFF
Number of registers (N)
2
1 – 123
Byte counter
1
2 * N
Values to be stored
2 * N
0x0000 – 0xFFFF
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
Response format:
Description
Size [Bytes]
Values
Notes
Address
1
1 – 247
Function code
1
0x10
Data block address
2
0x0000 – 0xFFFF
Number of registers (N)
2
1 – 123
CRC check sum
2
0x0000 – 0xFFFF
See section 4.4
