VTS VENTUS PRO PVS PO 30 EC [3/16] Parameters of co2 measurement
![VTS VENTUS PRO PVS PO 30 EC [3/16] Parameters of co2 measurement](/views2/1893541/page3/bg3.png)
VTS reserves the right to implement changes without prior notice.
www.vtsgroup.com Page 3 of 16 ver. 2.0 (11.2021)
2. Technical data
2.1. General parameters of the transducer
Power supply
DC voltage
DC 20-30 V (nom DC 24 V)
AC voltage
AC 20-28 V (nom AC 24 V)
Current consumption
typical
30 mA
max
100 mA
LED indicators
See section 3.5
Signal connection
Screw terminals in 5 mm pitch
(wire diameter ≤ 2.5 mm)
Housing dimensions
without sampling mast
80x82x55 mm
with sampling mast
80x82x280 mm
Weight
230g
Working environment
Dust-free, air, neutral gases
Working temperature
0ºC ÷ 50ºC
2.2. Parameters of CO2 measurement
Sensor model
MH-Z19B
Measurement range
0/400-2000 ppm
Measurement accuracy
± (5% of measured value + 50ppm)
Sampling period
5 s
Response time T90 *)
< 2 min
*) response time T90 is the time from moment of change of state to the moment when the
measurement value reaches 90% of the steady value.
