Sinbo SFH-3314 [8/16] Parts of the appliance

- 7 -

PARTS OF THE APPLIANCE

TECHNICAL SPECIFICATIONS

Rated Voltage : AC 230V

Frequency : 50 Hz

Power Consumption : 2500 W

Dimensions : 760x170x55 mm

Weight : 1,756 kg.

Effective area : 25 m

SPECIFICATIONS

• Healthy, economical and durable heater.

• Heats the environment in a short time

• Safety switch stops operation in case of tipping over

• On/Off switch

• Does not cause headaches since it does not consume oxygene.

• Does not dry air; does not cause bad odors since it does not burn particles in the air.

• Can be operated on the floor/desktop on its stand.

WALL ASSEMBLY

1. The heater shall be mounted on a sturdy surface like concrete, stone or metal. Do not

mount the unit on flammable surfaces.

2. 2pcs “L” brackets shall be fixed on the wall or to the ceiling parallel to the floor, using

2 fixing plugs with the identical distance between them

3. “L” brackets to be mounted on the and “L” brackets in the rear of the heater are fixed

to each othet using butterfly nuts upon adjusting the desired angle of the heater.

USING THE DEVICE

Note: Since the device is equipped with a safety switch it will not operate without placing

the unit on a flat surface.

Plastic

cover

(Left)

On/Off

Button

Plastic cover

(Right)

Power

Cord

Stand

Safety

Grill

Flament (Heating Element)
