03
FVS FAN COIL UNITS - WS
30
Performance data of F-VS-SD-2000-WS
F-VS-SD-2000-WS
Cooling Coil Air Inlet
Entering/Leaving Water Temperature
DB/WB
Speed
Air Flow
Rate
45/54 (°F); 7/12 (°C)
Total Cooling
Sensible Cooling
Water Flow rate
Water Pressure drop
m
3
/h
CFM
(X 1.000
Btu/Hr)
kW
(X 1.000
Btu/Hr)
kW
GPM
L/S
Ft.wg
kPa
76/63
HI
3381
1990
53073
15,55
43194
12,66
12,20
0,77
8,50
25,42
MED
3109
1830
49026
14,36
39836
11,67
11,30
0,71
7,40
22,13
LOW
2387
1405
37420
10,96
30449
8,92
8,80
0,56
4,70
14,05
80/63
HI
3381
1990
57425
16,83
52175
15,29
13,20
0,83
9,80
29,30
MED 3109
1830
53558 15,69
48393 14,18
12,40
0,78 8,70
26,01
LOW 2387
1405
41621 12,19
37408 10,96
9,80
0,62 5,70
17,04
85/63
HI
3381 1990
62833 18,41
62833
18,41 14,40
0,91 11,40
34,09
MED 3109
1830
58550 17,16
58550 17,16
13,40
0,85 10,10
30,20
LOW 2387
1405
47408 13,89
46078 13,50
11,10
0,70 7,10
21,23
76/65
HI 3381 1990 60789 17,81 41863 12,27 14,00 0,88 10,80 32,29
MED 3109 1830 57166 16,75 39029 11,44 13,20 0,83 9,70 29,00
LOW 2387 1405 44980 13,18 30335 8,89 10,60 0,67 6,50 19,44
80/65
HI 3381 1990 63121 18,49 50120 14,69 14,60 0,92 11,70 34,98
MED 3109 1830 59343 17,39 46664 13,67 13,80 0,87 10,60 31,69
LOW 2387 1405 46966 13,76 36399 10,66 11,00 0,69 7,00 20,93
85/65
HI 3381 1990 67064 19,65 60622 17,76 15,40 0,97 12,80 38,27
MED 3109 1830 62749 18,39 56262 16,48 14,40 0,91 11,40 34,09
LOW 2387 1405 50166 14,70 44155 11,70 13,20 0,83 7,90 23,62
76/67
HI 3381 1990 70385 20,62 41005 12,01 16,10 1,02 13,90 41,56
MED 3109 1830 66567 19,50 38444 11,26 15,40 0,97 12,90 38,57
LOW 2387 1405 54474 15,96 30781 9,02 12,70 0,80 9,10 27,21
80/67
HI 3381 1990 71812 21,04 48648 14,25 16,60 1,05 14,70 43,95
MED 3109 1830 67561 19,80 45374 13,29 15,60 0,98 13,20 39,47
LOW 2387 1405 55195 16,17 36151 10,59 12,90 0,81 9,30 27,81
85/67
HI 3381 1990 73445 21,52 58619 17,18 17,00 1,07 15,40 46,05
MED 3109 1830 68975 20,21 54560 15,99 16,00 1,01 13,80 41,26
LOW 2387 1405 55972 16,40 43176 12,65 13,00 0,82 9,50 28,41
