04
FVS FAN COIL UNITS - WD
39
District cooling (WD) - Product family and general technical specification
Rated parameters
Units
Speed
F-VS-SD-1000-WD
F-VS-SD-1200-WD
F-VS-SD-600-WD (HS)
F-VS-SD-800-WD (HS)
Low Static District Cooling Unit
High Static District Cooling Unit
Cooling Capacity
at DBT 76°F / WBT 63°F
water at (5.5°C / 14.5°C)
(42°F/58°F)
Total
BTU/hr
Med Speed
26826
28055
14109
17525
Sensible
[BTU/hr]
Med Speed
21770
23389
11176
14230
Cooling Capacity
at DBT 76°F / WBT 63°F
water at (5.5°C / 14.5°C)
(42°F/58°F)
Total
KW
Med Speed
7,86
8,22
4,13
5,13
Sensible
KW
Med Speed
6,38
6,85
3,27
4,17
Air Flow at 0,2"
wg (Low Static Unit)
-
[CFM]
Med Speed
1000
1120
-
-
Air Flow at 0,0
wg (Low Static Unit)
-
[CFM]
Med Speed
1270
1366
-
-
Air Flow at 0,4"
wg (High Static Unit)
-
[CFM]
Med Speed
-
-
354
473
Air Flow at 0,2
wg (High Static Unit)
-
[CFM]
Med Speed
-
-
480
641
Sound Pressure Level
according
to ISO 11203 at 1 meter
from the unit
-
[dB(A)]
High Speed
53
53
48
53
-
[dB(A)]
Med Speed
47
48
46
51
-
[dB(A)]
Low Speed 41
43 43
48
Coil
Type
[-]
-
3/8" ,0.28mm Thick Copper tubes
Row / FPI
[-]
- 4/10.58 4/10.58 4/15 4/15
Nominal water
ow rate
US GPM
Med Speed 3,50 4,20 2,25 3
Fan
Type
[-]
- Centrifugal , Forward Curve DIDW
Material
[-]
- GI
Quantity
[mm x mm]
- 4 4 1 1
Fan motor
Power Supply
(Output)
[W]
- 160 160 100 150
Power Input (Med)
[W]
- 273 302 185 250
RLA (Med)
[A]
- 1,19 1,31 0,80 1,09
Type/Class/IP
[-]
- Class B/IP20 Class B/IP20 Class B/IP20 Class B/IP20
Revolutions
[rpm]
H/M/L 1400/1330/1200 1400/1330/1200 1350/1250/1000 1350/1250/1000
Drive method - [-] - Direct Drive
Weight
Unit [kg] - 41 45 26 29
Shipping [kg] - 44 50 28 31
Unit Dimensions
L [mm] - 1690 1890 890 940
W [mm] - 550 +/-5 630 +/-5
H [mm] - 250 +/-5 335 +/-5
Shipping Dimensions
L [mm] - 1715 1915 905 955
W [mm] - 560 +/-5 640 +/-5
H [mm] - 260 +/-5 345 +/-5
Connections
Inlet (MPT) [inch] - 3/4" NPS 3/4" NPS 1/2" NPS 3/4" NPS
Outlet (MPT [inch] - 3/4" NPS 3/4" NPS 1/2" NPS 3/4" NPS
Drain Pipe Size [inch]
- 3/4
3/4
3/4 3/4
