2.1. Technical parameters
Table.1. Dimension and connection diameter
Pump circuit type
Foam
casing
type
Circuit casing dimension [mm]
Connection diameter *
Circuit set dimension [mm]
Lc
Wc
Hc
[inch]
DN
L
W
H
WPG - 25-070 - 2.5
S
540
305
230
3/4"
20
436
135
165
WPG - 25-070 - 4.0
1"
25
448
135
176
WPG - 25-070 - 6.3
1"
25
448
135
176
WPG - 25-095 - 4.0
1"
25
448
135
182
WPG - 25-095 - 6.3
1"
25
448
135
182
WPG - 25-070 - 10
L
690
355
270
1 1/4"
32
436
191
195
WPG - 25-095 - 10
1 1/4"
32
521
191
200
WPG - 25-095 - 16
1 1/4"
32
521
191
220
WPG - 25-105 - 16
1 1/4"
32
566
191
220
* female thread diameter
Table.2.Technical data
Pump
3 way valve
Actuator
Type
mass
[kg]
Voltage
P
max.
[W]
Max.
current
[A]
Max.
water
temp.
[C]
Ambient
temp.
[C]
Max
work.
Pressure
[bar]
Overload
protection
IP
k
vs
Max.
water
temp
[C]
IP
Voltage
WPG - 25-070 - 2.5
5,4
1 x 230V/50Hz
52
0,52
110
0..40
10
integrated
44
2,5
120
54
24VAC
WPG - 25-070 - 4.0
6,2
1 x 230V/50Hz
52
0,52
4
WPG - 25-070 - 6.3
6,4
1 x 230V/50Hz
52
0,52
6,3
WPG - 25-070 - 10
8,9
1 x 230V/50Hz
52
0,52
10
WPG - 25-095 - 4.0
6,6
1 x 230V/50Hz
140
1,1
4
WPG - 25-095 - 6.3
6,8
1 x 230V/50Hz
140
1,1
6,3
WPG - 25-095 - 10
10,9
1 x 230V/50Hz
140
1,1
10
WPG - 25-095 - 16
11,8
1 x 230V/50Hz
140
1,1
16
WPG - 25-105 - 16
13,7
1 x 230V/50Hz
180
1,4
16
*Additional information for the elements of the group can find in the suppliers manuals.
Table.3. Pump types used in the pump group
Pump circuit type
Used type of pump
WPG - 25-070..
UPM3 25-70 Flex AS
WPG - 25-095..
UPML 25-95 AUTO
WPG - 25-105..
UPMXL 25-105 AUTO
