KLQ - CO2 - W ⁄ KFTM - CO2 - W ⁄ KFTM - LQ - CO2 - W ⁄ KTM - CO2 - SD
Rev. 2021 - V33
Patented quality product (patent no. DE 10 2014 010 719.1)
Maintenance-free duct sensor
AERASGARD
®
KTM - CO2 - SD
with active output, automatic calibration, in an impact-resistant plastic housing with
quick-locking screws, for determining the CO2 content of the air (0...2000 ppm/0...5000 ppm) and the temperature (–35...+80 °C). The measuring
transducer converts the measured values into a standard signal of 0 -10 V.
Maintenance-free duct sensor
AERASGARD
®
KFTM - LQ
- CO2 - W
with active/switching output, automatic calibration, in an impact-resistant plastic
housing with quick-locking screws, optionally with/without Display, for determining the CO2 content of the air (0...2000 ppm/0...5000 ppm), the
quality (0…100 % VOC), the temperature (–35...+80 °C) as well as the relative air humidity (0…100 % r.H). The measuring transducer converts the
measured values into a standard signal of 0 -10 V or 4...20 mA (switchable).
The sensor is used in offices, hotels, convention centres, apartments, shops, etc. for the purpose of evaluating the indoor climate. This enables
energy-saving room ventilation on an as-needed basis, thereby reducing operating costs and improving well-being. One sensor for every 30 m² of
space is recommended.
A long-term stable,
digital humidity and temperature sensor
guarantees exact measurement results. The CO2 measurement is performed using an
optical
NDIR sensor
(non-dispersive infra-red technology). The detection range is calibrated for standard applications such as monitoring residential
rooms and conference rooms. The air quality is detected by a
VOC sensor
(mixed gas sensor for volatile organic substances). This sensor deter-
mines the loading of the room air due to contaminated gases such as cigarette smoke, body perspiration, exhaled breathing air, solvent vapours,
emissions etc. With regard to the expected air contamination, low, medium or high VOC sensitivity can be selected. As an alternative, use IAQ
categories (from excellent to unhealthy) following the guidelines of the German Federal Environmental Agency to assess the room air.
TECHNICAL DATA
Voltage supply: 24 V AC ⁄ DC (± 10 %)
Power consumption: < 4.8 W ⁄ 24 V DC typical; < 6.8 VA ⁄ 24 V AC typical; peak current 200 mA
Outputs:
KTM - CO2 - SD
0 -10 V (fixed)
Kxx - CO2 - W
0 -10 V
or
4...20 mA, working resistance < 800 Ω
(selectable via DIP switches, selected variant applies for all outputs),
with offset potentiometer (± 10 % of the measuring range)
Relay output:
KTM - CO2 - SD
without changeover contact
Kxx - CO2 - W
with potential-free
changeover contact
(24 V / 1 A)
(assignment selectable via DIP switches, switchpoint adjustable)
HUMIDITY
Sensors:
digital humidity sensor with integrated temperature sensor,
low hysteresis, high long-term stability
Sensor protection: plastic sinter filter, Ø 16 mm, L = 35 mm, exchangeable
(optional metal sinter filter, Ø 16 mm, L = 32 mm)
Measuring range, humidity: 0...100 % r. H.
Operating range, humidity: 0...95 % r. H. (without dew formation)
Deviation of humidity: typically
± 2.0 %
(20...80 % r. H.) at +25 °C, otherwise ± 3.0 %
Output, humidity: 0 -10 V
or
4...20 mA
(
selectable via DIP switches)
TEMPERATURE
Measuring range, temperature: –35...+80 °C
Operating range, temperature
:
–10...+60 °C
Temperature deviation: typically ± 0.2 K at +25 °C
Output, temperature:
KTM - CO2 - SD
0 -10 V (fixed)
Kxx - CO2 - W
0 -10 V
or
4...20 mA
(
selectable via DIP switches)
AIR QUALITY (VOC)
Sensor, VOC: VOC sensor (metal oxide) (VOC = volatile organic compounds),
with manual calibration (using zero button) and
automatic calibration (permanently active)
Measuring range, VOC: 0...100 % air quality; referred to calibrating gas;
multi-range switching
(selectable via DIP switches)
VOC sensitivities (low/medium/high) or IAQ category (Indoor Air Quality)
Output, VOC: 0 -10 V (0 V = clean air, 10 V = polluted air)
or
4...20 mA (selectable via DIP switches,
switchpoint can be adjusted from 0...100 % of the output signal)
Measuring accuracy, VOC: typically ± 20 % of final value (referred to calibrating gas)
Service life: > 60 months (under normal load conditions)
depending on the type of loading and gas concentration
CARBON DIOXIDE (CO2)
Sensor, CO2:
optical NDIR sensor
(non-dispersive infra-red technology),
with manual calibration (via zero button),
KTM - CO2 - SD
with automatic calibration (fixed)
Kxx - CO2 - W
with automatic calibration (can be deactivated via DIP switches)
Measuring range, CO2: 0...2000 ppm
or
0...5000 ppm (selectable via DIP switches)
Output, CO2:
KTM - CO2 - SD
0 -10 V (fixed)
Kxx - CO2 - W
0 -10 V
or
4...20 mA (selectable via DIP switches)
Measuring accuracy, CO2: typically ± 30 ppm ± 3 % of measured value
Temperature dependence, CO2: ± 5 ppm ⁄ °C or ± 0.5 % of measured value ⁄ °C
(whichever is higher) continued on next page!
