Brother PJ-600/700/800 Series Command Reference
9
© 2015 Brother Industries, Ltd. All Rights Reserved.
3.2.3. Page size (200 dpi model)
・Fixed length
*When the paper type is set to “cut sheet” or “perforated roll retract”
Paper
A
B
C
D
E
F
G
H
A4
297.0 mm
2338 dots
2.5 mm
20 dots
279.4 mm
2200 dots
15.0 mm
118 dots
210.0 mm
1654 dots
3.4 mm
27 dots
203.2 mm
1600 dots
3.4 mm
27 dots
Legal
355.6 mm
2800 dots
2.5 mm
20 dots
347.1 mm
2733 dots
6.0 mm
47 dots
215.9 mm
1700 dots
4.3 mm
34 dots
207.2 mm
1632 dots
4.3 mm
34 dots
Letter
279.4 mm
2200 dots
2.5 mm
20 dots
270.9 mm
2133 dots
6.0 mm
47 dots
215.9 mm
1700 dots
4.3 mm
34 dots
207.2 mm
1632 dots
4.3 mm
34 dots
A5
210.0 mm
1653 dots
2.5 mm
20 dots
193.8 mm
1526 dots
13.6 mm
107 dots
148.0 mm
1165 dots
3.4 mm
27 dots
141.1 mm
1111 dots
3.4 mm
27 dots
Custom
Size Min
50.8 mm
400 dots
2.5 mm
20 dots
42.2 mm
333 dots
6.0 mm
47 dots
101.6 mm
800 dots
3.4 mm
27 dots
94.7 mm
746 dots
3.4 mm
27 dots
Custom
Size
Max
2540.0 mm
20000 dots
2.5 mm
20 dots
2531.4 mm
19933 dots
6.0 mm
47 dots
215.9 mm
1700 dots
3.4 mm
27 dots
207.2 mm
1632 dots
5.2 mm
41 dots
*When the paper type is set to “roll”
Paper
A
B
C
D
E
F
G
H
A4
297.0 mm
2338 dots
10.9 mm
93 dots
280.0 mm
2198 dots
6.0 mm
47 dots
210.0 mm
1654 dots
3.4 mm
27 dots
203.2 mm
1600 dots
3.4 mm
27 dots
Legal
355.6 mm
2800 dots
10.9 mm
86 dots
338.7 mm
2667 dots
6.0 mm
47 dots
215.9 mm
1700 dots
4.3 mm
34 dots
207.2 mm
1632 dots
4.3 mm
34 dots
Letter
279.4 mm
2200 dots
10.9 mm
86 dots
262.5 mm
2067 dots
6.0 mm
47 dots
215.9 mm
1700 dots
4.3 mm
34 dots
207.2 mm
1632 dots
4.3 mm
34 dots
A5
210.0 mm
1653 dots
10.9 mm
86 dots
193.0 mm
1520 dots
6.0 mm
47 dots
148.0 mm
1165 dots
3.4 mm
27 dots
141.1 mm
1111 dots
3.4 mm
27 dots
Custom
Size Min
50.8 mm
400 dots
10.9 mm
86 dots
33.9 mm
267 dots
6.0 mm
47 dots
101.6 mm
800 dots
3.4 mm
27 dots
94.7 mm
746 dots
3.4 mm
27 dots
Custom
Size
Max
2540.0 mm
20000 dots
10.9 mm
86 dots
2523.1 mm
19867 dots
6.0 mm
47 dots
215.9 mm
1700 dots
3.4 mm
27 dots
207.2 mm
1632 dots
5.2 mm
41 dots
