![Brother PJ-723 [16/62] Status](/views2/1897104/page16/bg10.png)
Brother PJ-600/700/800 Series Command Reference
13
© 2015 Brother Industries, Ltd. All Rights Reserved.
4. Status
4.1. Overview
The status is sent from the printer to the computer as a reply to the "status information request"
command or as an error message. The size is fixed to 32 bytes.
Number
Offset
Size
Name
Value/Reference
1
0
1
Print head mark
Fixed to “80 Hex”
2
1
1
Size
Fixed to “20 Hex”
3
2
1
Reserved
Fixed to ’B’ (42 Hex)
4
3
1
Series code
Refer to section 4.2.1.
5
4
1
Model code
Refer to section 4.2.1.
6
5
1
Reserved
Fixed to '0' （30 Hex）
7
6
1
Battery and Power
Supply Information
Refer to section 4.2.2
8
7
1
Reserved
Fixed to “00 Hex”
9
8
1
Error information 1
Refer to section 4.2.3.
10
9
1
Error information 2
Refer to section 4.2.3.
11
10
1
Paper width
Refer to section 4.2.4.
12
11
1
Paper loaded
Refer to section 4.2.5.
13
12
1
Reserved
Fixed to “00 Hex”
14
13
1
Reserved
Fixed to “00 Hex”
15
14
1
Reserved
Fixed to “00 Hex”
16
15
1
Reserved
Fixed to “00 Hex”
17
16
1
Reserved
Fixed to “00 Hex”
18
17
1
Paper Length (Lower order
bytes)
Refer to section 4.2.5.
19
18
1
Status type
Refer to section 4.2.6.
20
19
1
Phase type
Refer to section 4.2.7.
21
20
1
Higher order bytes of phase
number
Refer to section 4.2.7.
22
21
1
Lower order bytes of phase
number
Refer to section 4.2.7.
23
22
1
Notification number
Refer to section 4.2.8.
24
23
1
Reserved
Fixed to “00 Hex”
25
24
8
Reserved
Fixed to “00 Hex”
