IMPORTANT! If the pieces are dissolved at a temperature of
34ºC and above, then there is a big chance that the chocolate
won’t contain the required quantity of stable crystals. If the set
temperature is reached, and the pieces are not melted, then
cover the container with a lid and repeat stirring after 10-15
minutes until the pieces are completely dissolved.
— Collect the probe and check the quality of the tempering;
— Upon finishing the work, set the temperature to 40-50ºC,
cover with a lid;
— To start the work, repeat all the steps again.
7.2.2. Method B — Classic tempering:
— Heat up the chocolate to 42-45ºC (or other temperature
recommended by chocolate manufacturer);
— Change the temperature value on the controller to fit the
working temperature of the chocolate (33ºC or the value
recommended by the chocolate manufacturer);
— Remove a bit of chocolate from the container and pour it on
a marble or granite table;
— Methodically mixing chocolate on a cold table surface,
lower the temperature to 26-27ºC. The look of the chocolate
can also serve as an indicator of a successful result: the
surface of the mass should change its gloss to matte, the
chocolate becomes much thicker.
— Collect the chocolate in a cup and return it to the tempering
container. Mix thoroughly. The temperature of the chocolate
12
