Parts
Fluid Fluid
Fluid
Heater Heater
Heater
24U843 24U843
24U843
— —
—
10kW, 10kW,
10kW,
2–zone 2–zone
2–zone
24U842 24U842
24U842
— —
—
7.5 7.5
7.5
kW, kW,
kW,
1–zone 1–zone
1–zone
1
Torqueto120ft-lbs(163N•m).
2
Torqueto23ft-lbs(31N•m).
3
Torqueto40ft-lbs(54N•m).
4
Applythermalpaste.
5
ApplypipesealantandPTFEtapetoallnon-swivelingthreadsandthreadswithouto-rings.
6
Applylithiumgreaselubricanttoo-ringsbeforeassemblinginblock(1).
7
RemovetapefromprobetipandOrientatesensorasshown.Insertprobeuntilitbottomsonheatingelement.
Tightenferruleonsensorprobeoneturnpastngertightor16ft-lbs(21.6N•m).
88 333024T
