Spraying
4.Acceptorcancelthehosecalibration.
NOTE: NOTE:
NOTE:
Atemperatureestimatewillbedisplayed
ifthesystemwasabletomeasurethehosewire
resistance.
Standby Standby
Standby
Ifyoustopsprayingforaperiodoftime,theunitwill
enterstandbybyshuttingdowntheelectricmotor
andhydraulicpump,toreduceequipmentwearand
minimizeheatbuildup.ThepumpiconontheADM
Homescreenwillashwheninstandby.
NOTE: NOTE:
NOTE:
TheA,B,andHoseheatzoneswillnotshut
offduringstandby.
Torestart,sprayofftargetfortwoseconds.The
systemwillsensethepressuredropandthemotor
willrampuptofullspeedinafewseconds.
NOTE: NOTE:
NOTE:
Thisfeatureisdisabledfromthefactory.
Toactivateordeactivatestandby:
1.Entersetupmodebypressing
ontheADM.
2.GotoscreenSystem3andselectto
enter
thepageforediting.
3.Selectthe“StandbyIdleTime”drop-downusing
andthearrowkeys.Selectthedesireddelay
using
andthearrowkeys.Pressenterto
selectthedesiredvalue.
4.Exitthepageandreturntorunmodebypressing
,then.
58 334945J
