Topreventseriousinjury,onlyoperateReactor
withallcoversandshroudsinplace.
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensure
steadyvoltage.Failuretofollowthese
procedureswillcausevoltageuctuationsthat
candamageelectricalequipment.
1.FollowthePressureReliefProcedure,page
32.
2.Checktheuidinletlterscreens.
Beforedailystartup,ensurethatthe
uidinletscreensareclean.See
FlushInletStrainerScreen,page52.
ti36987b
ZE
ZA
ZC
ZB
XA or XB
3.ChecktheISOLubricationReservoir(TS).
ChecklevelandconditionofISOlubedaily.
SeePumpLubricationSystem.
4.UseAandBDrumLevelSticks(24M174)to
measurethemateriallevelineachdrum.If
desired,thelevelcanbeenteredandtracked
withtheADM.
5.Checkthegeneratorfuellevel.
NOTICE NOTICE
NOTICE
Runningoutoffuelwillcausevoltage
uctuationsthatcandamageelectrical
equipment.Donotrunoutoffuel.
6.Conrmthesystemmainpowerswitch(MP)
isOFFbeforestartinggenerator.
ti39681a
MP
7.Ensurethemainbreakeronthegeneratoris
intheOFFposition.
8.Startthegenerator.Allowthegeneratorto
reachfulloperatingtemperature.
9.TurnthegeneratormainbreakertotheON
position.
10.Turnthesystemmainpowerswitch(MP)ON.
W
WLL DD
3A8500E 29
