![Graco REACTOR 3 E-30 26R330 [16/26] Hose control modes](/views2/1900731/page16/bg10.png)
Operation
16 3A7683G
Hose Control Modes
The target temperature of component materials can be
controlled using one of three hose control modes. Set
your preferred hose control mode using the Advanced
Display Module on the Reactor system. See your
proportioner manual to set the hose control mode. See
Related Manuals, page 2.
Pressure Relief Procedure
Before disconnecting or repairing hoses, relieve all fluid
pressure and shut off electrical power to proportioner.
Follow the Pressure Relief Procedure in your Reactor
Proportioning System manual. See Related Manuals,
on page 2.
Hose
Control
Mode
Description
FTS Mode The fluid temperature sensor (FTS)
installed in the hose automatically controls
the hose fluid temperature. This mode
requires the FTS to be installed and
working properly. See your FTS kit manual,
Related Manuals, on page 2.
Resistance
Mode
The hose heater element resistance
automatically controls hose fluid
temperature. This mode does not use an
FTS. This mode requires a calibration
factor (see your proportioner manual).
Manual
Control
Mode
Control to target current (amps) to heat the
hose. Manual control mode has no
pre-programmed control and is designed
to be used for a limited amount of time
until a proper calibration can be performed
or FTS issues can be resolved.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
pressurized fluid, such as skin injection and
splashing fluid, follow the Pressure Relief Procedure
when you stop spraying and before cleaning,
checking, or servicing the equipment.
