Technical Specifications
3A7683G 25
Technical Specifications
California Proposition 65
Reactor 3 Heated Hose
US Metric
Whip Hose
Maximum Fluid Working Pressure
25P775 2000 psi 14 MPa, 138 bar
25P776 2000 psi 14 MPa, 138 bar
19D576 2000 psi 14 MPa, 138 bar
25P777 3500 psi 24 MPa, 241 bar
25P778 3500 psi 24 MPa, 241 bar
Two Component Hose
Maximum Fluid Working Pressure
25P434 2000 psi 14 MPa, 138 bar
25P435 2000 psi 14 MPa, 138 bar
25P437 2000 psi 14 MPa, 138 bar
25P438 2000 psi 14 MPa, 138 bar
25P534 3500 psi 24 MPa, 241 bar
25P535 3500 psi 24 MPa, 241 bar
25P537 3500 psi 24 MPa, 241 bar
25P538 3500 psi 24 MPa, 241 bar
Hose
Maximum Operating Temperature
2000 psi 160 °F 71.1 °C
3500 psi 180 °F 82.2 °C
Wetted Parts
Material
Chemically resistant polymeric material,
stainless steel, plated carbon steel
Notes
All trademarks or registered trademarks are the property of their respective owners.
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov.
