Installation
309572ZAT 17
Connect FTS and Heated Dual Whip Hose
NOTE: See FIG. 13 on page 18.
NOTE: For 1/2 in. (13 mm) ID fluid hoses only: Prior
to connecting the FTS, remove the adapters from the
proportioner fluid manifold and install them on the male
ends of the hoses (1 and 2). Torque the A side hose to a
maximum of 43 ft-lbs (58 N•m) and the B side hose to a
maximum of 55 ft-lbs (74 N•m). Continue on to step 1.
1. Assemble JIC swivel fitting (5e) in female end of
temp sensor (5a). Do not bend or kink probe.
Torque connection to 14 ft-lbs (19 N•m). Do not
over-torque. Assemble JIC swivel fitting (5d) into
female end of B hose coupler (5b). Torque to a
maximum of 20 ft-lbs (27 N•m). Do not over-torque.
2. Carefully inset FTS probe into the A hose (1)
section from the proportioner. Do not bend or kink
probe. Connect to A side whip (6a). Torque fitting
connections to 14 ft-lbs (19 N•m). Do not
over-torque.
3. Connect the B hose coupler to the B hose section
(2) and B side whip (6b). Torque fitting connections
to 20 ft-lbs (27 N•m). Do not over-torque.
4. Connect ground wire (K) of whip hose to the ground
screw on the FTS (5a).
NOTE: Whip hose ground wire (K) must be connected
to the ground screw on the FTS (5a) in order to drain
static from the gun. If the FTS is not directly connected
to the whip hose, a hose that includes a separate
ground wire must be used between the FTS and whip
hose. Connect ground through a hose marked as not
having the FTS cable selected from the “Standard 2
Component Hose” table in the front of this manual.
NOTE: Ground wire K not included in whip hoses
25P770, 25P771, 25P772, 25P773. To properly ground
these assemblies, connect FTS fittings to whip hose
fittings.Grounding capability is built into the hose.
5. Connect the electrical connectors (12).
6. Connect the FTS air line coupler (5c) between air
hoses (3 and 8).
7. Connect the sensor cable of the hose (4) to the
sensor cable of the FTS (5a). For non-RTD hoses,
slide the insulator sleeves (S) over the connection.
Leave slack in the cables to provide stress relief and
to prevent cable failure or errors.
8. See Connect Hoses to Proportioner, page 20.
9. Cover the FTS and spacer with split foam (provided)
and tape closed.
NOTICE
To prevent damage to probe, do not kink or
excessively bend hose. Do not coil hose tighter than
the minimum bend radius of 1.5 ft (0.5 m). Do not
subject hose to excessive weight, impact, or other
abuse.
NOTICE
To avoid damage to FTS sensor cable, rotate FTS
body so the cable lays between both fluid hoses to
protect it from abrasive damage during use.
A grounding wire must be used to provide grounding.
