Wall-mounting

Take the following steps to hang your P-870H/HW Series on a wall.

1. Select a position free of obstructions on a sturdy wall.

2. Drill two holes for the screws, exactly 120 mm apart.

3. Be careful to avoid damaging pipes or cables located inside the wall

when drilling holes for the screws.

4. Do not insert the screws all the way into the wall. Leave a small gap of

about 0.5 cm between the heads of the screws and the wall.

5. Make sure the screws are snugly fastened to the wall. They need to

hold the weight of the P-870H/HW Series with the connection cables.

6. Align the holes on the back of the P-870H/HW Series with the screws

on the wall. Hang the P-870H/HW Series on the screws.
