9
GB
3. Press the programming button. The indicator
light corresponding to the selected zone will start
flashing.
4. Set the cooking duration using the
-
and
+
buttons.
5. Confirm by pressing the
button or automatic
selection occurs after 10 seconds.
The timer begins counting down immediately. A buzzer
sounds for approximately 1 minute and the cooking
zone switches off when the set programme has
finished.
Repeat the above procedure for each hotplate you
wish to programme.
Using multiple programmes and the display
If one or more hotplates are programmed, the display
will show the data for the hotplate with
the least time remaining, and the light
corresponding to the position of the
hotplate will flash. The lights corresponding
to the other hotplates programmed will be switched on.
To visualise the time remaining for the other programmed
hotplates, press the
button repeatedly: the time
remaining for each hotplate will be shown sequentially
in a clockwise order, starting from the front left
hotplate.
Changing the programme
1. Press the
button repeatedly until the duration you
wish to change is shown.
2. Use the buttons to set the new duration.
3. Confirm by pressing the
button.
To cancel a programme, follow the above instructions. At
step 2, press the
-
button: the duration decreases
progressively until it reaches 0 and switches off. The
programme resets and the display exits programming
mode.
Timer
The hob must be switched on.
The timer can be used to set a duration up to 99 minutes.
1. Press the
programming button until the timer
indicator light is illuminated
.
2. Set the desired duration using the
-
and
+
buttons.
3. Confirm by pressing the button.
The timer begins counting down immediately. When
the time has elapsed, a buzzer will sound (for one
minute).
Control panel lock
When the hob is switched on, it is possible to lock the oven
controls in order to avoid accidental changes being made
to the settings (by children, during cleaning, etc.). Press
the
button to lock the control panel: the indicator
light above the button will switch on.
To use any of the controls (e.g. to stop cooking), you
must switch off this function. Press the
button for a
few moments, the indicator light will switch off and the
lock function will be removed.
Switching off the hob
Press the button to switch off the appliance - do not
rely solely on the pan sensor.
If the control panel lock has been activated, the
controls will continue to be locked even after the hob is
switched on again. In order to switch the hob on again,
you must first remove the lock function.
“Demo” mode
It is possible to set the hob to a demonstration mode where
all the controls work normally but the heating elements do
not switch on. To activate the “demo” mode the hob must
be switched on, with all the hotplates switched off.
• Press and hold the
+
and
-
buttons simultaneously
for 6 seconds. When the 6 seconds have elapsed,
the ON/OFF and CONTROLS LOCKED indicator
lights will flash for one second. Release the
+
and
-
buttons and press the button;
• The display will show the text DE and MO and the hob
will be switched off.
• When the hob is switched on again it will be set to the
“demo” mode.
To exit this mode, follow the procedure described above.
The display will show the text DE and OF and the hob will
be switched off. When it is next switched on, the hob will
function normally.
