Graco XP70s-hf 577333 [60/86] Xp50s hf and xp70s hf proportioner
![Graco XP70s-hf 577333 [60/86] Xp50s hf and xp70s hf proportioner](/views2/1906144/page60/bg3c.png)
Parts
60 3A6283H
Parts
XP50s-hf and XP70s-hf Proportioner
WLF
Label No.
16F359 C
Modifying this machine or adding
Non-approved accessories voids the
Hazardous Area Approvals.
La modificaci
ó
n de esta máquina o adici
ó
n de
accesorios no autorizados anula la zona
peligrosa de idoneidad.
Modification de cette machine ou de
l ajout
d accessoires non approuvés par les vides de
la zone dangereuse approbations.
1. Apply anaerobic pipe sealant to all
non-swiveling pipe threads.
