Note
Reversing the doors is not covered by the warranty.
18
18
18
24
25
17
17
31
17
28
28
29
33
2
4
26
19
20
21
32
20 21
23
22
5.
6.
Loosen the bolt to remove the middle hinge and sheet hinge,
then lift up the freezer door to separate it. Separate the cover
and set it on the right side.
Loosen the pin in counterclockwise direction and move to the
hole on the left side to tighten in clockwise direction. Loosen
the bolt to separate the lower hinge . Move the leveling
screw to the righe side.
21
8. Set the separate lower hinge on the bottom hole of the left
side of the refrigerator. Assemble the freezer door on the pin
of lower hinge to attach it properly. Turn over the separated
middle hinge and sheet hinge to assemble them. And set
the washer .
7. Unscrew the screw under the freezer door , move the
door stopper to the left of the freezer door. Move the bush
to the left of the freezer door. And than move the cap to
the righe side and cover it.
9.After assembling the door by aligning the hinge hole on the
bottom of the refrigerator door and the pin of the middle
hinge , connect properly to the hold of the upper left hinge
included in the owner’s manual. After connecting the cable
.Use bolt to fixation the left hinge ,then assemble the
left hinge cover included in the owner’s manual with the screw.
Take the right cap out of the alternate bag, then install it on
the right side of the refrigerator top.
30
17
26
19
28
29
33
2
4
17
21
18
20
21
22
31
32
18
25
24
23
