LG GR-B359BQA [18/26] Operation
![LG GR-B359BQA [18/26] Operation](/views2/1091427/page18/bg12.png)
Operation
Lock
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the ‘CHILD LOCK’ button. (For “Locking” or
“Un-Locking” press the ‘CHILD LOCK’ button for 2 secs.)
• When ‘CHILD LOCK’ is activated, pressing the other
buttons would not work.
Self Test
This function allows you to check for operational
problems. If you think you have a problem with your
fridge-freezer, then press the temperature control
button:
- If the indicate lights move up or down, then there is no
problem with your fridge-freezer.
- If the indicate lights do not move up or down, then
please leave the power connected and call your nearest
service agent.
Ice Making
• To make ice cubes, fill the ice
tray to the water level and place
it in the freezer.
• If ice cubes are required fast,
press the ‘SUPER FRZ.’ button.
• To remove ice cubes, hold the
tray at its ends and twist gently.
Tip
To remove ice cubes easily, run water on the tray
before twisting.
Defrosting
Defrosting takes place automatically.
The defrosting water flows down to the evaporating tray
and is evaporated automatically.
20
