To Reverse the Doors
Precaution
1.
2.
3.
4.
How to Reverse the Door
1.
To separate the door handle of the left side, separate the
door cap and unscrew the screw in counterc
lockwise
direction.Separate the door handle of the freezer
in the
same order. (You do not need to follow the above pr
ocedure
for the hidden
handle.)
2
1
3
4
2.After unscrewing the screw of the right hinge cover on
the top, separate the right hinge cover to separ
ate the
connecting cable .Separate the bolt fixating th
e upper
right hinge ,and carefully separate the refrigerator door .
3.After separating the upper left cap of the separated
refrigerator door , carefully take off the top ca
p and
pull the cable to connect to the hole on the left s
ide.Set
the separated top cap at the regular position and
set the
cap on the cable hole on the right side.Loosen the s
crew
under the cold room door , move it to the left of
the
stopper , and then connect
it.
5
5
6
8
11
13
7
10
10
9
12
11
12
32
31
10
2
1
4
3
2
3
2
26
Your fridge-freezer is designed with reversible doors,so that they may open from either
the left or right hand side to suit your kitchen design.
Before reversing the door, first of all,you should take out food and accessories like
shelves or trays which are not fixed in the fridge-freezer.
Use Torque Wrench or Spanner to fix or remove the bolt.
Do not lay the fridge-freezer down.This will cause problems.
Be careful not to drop the doors in disassembling or assenbling
.
10
11
12
13
31
32
5
6
7
9
8
10
4.Use a sharp gimlet or knife to disconnect the cap from the
cover front , loosen the screw , and then move the cable
to the left to be mounted. Disconnect the cable and the
door switch from the disconnected cover front , swap the
position of the disconnected cable and door switch with
the cap , mount them, fix them with the screw , and then
install the cap .
