MPG X570S CARBON MAX WIFI

GAME IN STYLE

SPECIFICATIONS

Model Name MPG X570S CARBON MAX WIFI

CPU Support

Supports AMD Ryzen

™

5000 Series, 5000 G-Series, 4000 G-

Series, 3000 Series, 3000 G-Series, 2000 Series and 2000 G-

Series desktop processors

CPU Socket AM4

Chipset AMD X570 Chipset

Graphics

Interface

2x PCIe 4.0 x16 slots

Support AMD CrossFire

™

Technology

Display Interface Support 4K@60Hz as speciﬁed in HDMI 2.1 – Requires

Processor Graphics

Memory Support 4 DIMMs, Dual Channel DDR4-5300+ (OC)

Expansion Slots 2x PCIe 3.0 x1 slot

Storage 4x M.2 Gen4 x4 64Gb/s slots

8 x SATA 6Gb/s

USB ports 5x USB 3.2 Gen 2 10Gbps (3 Type-A + 2 Type-C)

8x USB 3.2 Gen 1 5Gbps (8 Type-A)

6x USB 2.0

LAN

Realtek

8125B 2.5G LAN

Wireless /

Bluetooth

Intel

Wi-Fi 6E AX210, Bluetooth 5.2

Audio 8-Channel (7.1) HD Audio with Audio Boost 5

FEATURES

Premium Thermal Design

Heavy plated mosfet heatsink with heat-pipe / high quality 7W/mK

mosfet thermal pads / extra choke thermal pads / 3x onboard M.2

Shield Frozr

Lightning Gen4 Solution

The latest Gen4 PCI-E and M.2 solution with up to 64GB/s

bandwidth for maximum transfer speed.

2.5G Network Solution

Featuring premium 2.5G LAN with LAN manager to deliver better

network experience.

Wi-Fi 6E

The latest wireless solution supports 6GHz spectrum, MU-MIMO

and BSS color technology, delivering speeds up to 2400Mbps.

Audio Boost 5

Isolated audio with a high quality audio processor & amp for the

most immersive gaming experience

Mystic Light RGB LED

Personalize your PC with 16.8 million colors / 29 eﬀects,

controlled in one click!

Core Boost

With premium layout and fully digital power design to support

more cores and provide better performance.

DDR4 Boost

Advanced technology to deliver pure data signals for the best

gaming performance and stability.

2oz Thickened Copper PCB

An enhanced PCB design improves heat dissipation and

performance reliability.

CONNECTIONS

1. Clear CMOS Button

3. USB 3.2 Gen 2 10Gbps Type-A

5. Audio Connectors

7. USB 2.0

9. USB 3.2 Gen 1 5Gbps Type-A

11. USB 3.2 Gen 2 10Gbps Type-A/C

2. Keyboard / Mouse

4. 2.5G LAN

6. Flash BIOS Button

8. HDMI

10. Wi-Fi / Bluetooth

12. Optical S/PDIF Out

Generated 2021-11-09, check for the latest version www.msi.com/datasheet. The information provided in this document is intended for informational purposes only and is subject to change without notice.
