2-9
OSD Setup
2-8
h Input Source
1st Level Menu Description
HDMI1 Users can adjust Input Source in any Mode�
HDMI2
DP
h PIP/PBP
1st Level Menu 2nd/3rd Level Menu Description
OFF ■ PIP (Picture in Picture) allows users to
simultaneously display multiple video
sources on one screen� One program is
displayed on the full screen at the same
time as one or more other programs are
displayed in inset windows�
■ PBP (Picture by Picture) is a similar feature
that displays two input sources side-by-side
on the screen�
■ PIP/PBP default is OFF�
■ Display Switch allows users to switch
between primary and secondary input
sources�
■ Audio Switch allows users to switch between
primary and secondary digital audio sources�
■ Customize: Press
M
button to go up;
button to go left;
button to go right;
E
button to go down; press
M
+ buttons to
save setting and exit�
PIP Source DP
HDMI1
HDMI2
PIP Size Small
Medium
Large
Location Left Top
Right Top
Left Bottom
Right Bottom
Customize
Display Switch
Audio Switch
PBP (X2) Source1 DP
HDMI1
HDMI2
Source2 DP
HDMI1
HDMI2
Display Switch
Audio Switch
h Navi Key
1st Level Menu 2nd Level Menu Description
Left
Right
Enter
OFF ■ Left Button default is Game Mode�
■ Right Button default is Screen Assistance�
■ Enter Button default is Input Source�
Brightness
Game Mode
Screen Assistance
Alarm Clock
Input Source
PIP/PBP Mode
Refresh Rate
Night Vision
Information on Screen
