- 8 -
2-2 ProductSpecications
CPU LGA1700 socket: Support for the 13th and 12th Generation Intel
®
Core
™
, Pentium
®
Gold and Celeron
®
Processors
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
Z790 Express Chipset
Memory Support for DDR5 5600/5200/4800/4400 MT/s memory modules
4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor+Intel
®
Thunderbolt
™
4 Controller:
2 x Intel
®
Thunderbolt
™
4 connectors (USB Type-C
®
ports), supporting DisplayPort
and Thunderbolt
™
video outputs and a maximum resolution of 5120x2880@60 Hz
with 24 bpp (via single display output)
* Because of the limited I/O resources of the PC architecture, the number of
Thunderbolt
™
devices that can be used is dependent on the number of the PCI
Express devices being installed. (Refer to Chapter 2-6, "Back Panel Connectors,"
for more information.)
* Support for DisplayPort 1.4 version and HDCP 2.3
(Graphics specications may vary depending on CPU support.)
Audio 1 ESS ES9280AC DAC chip + 2 ESS ES9080 chips
DTS
®
Sound Unbound
™
High Denition Audio
2-channel
Support for S/PDIF Out
* The line out jack and the optical S/PDIF out connector can only be used one at a
time.
LAN Marvell
®
AQtion AQC107 10GbE LAN chip (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/
100 Mbps) (LAN1)
Intel
®
2.5GbE (2.5 Gbps/1 Gbps/100 Mbps) (LAN2)
Wireless
Communication
Module
Intel
®
Killer
™
Wi-Fi 6E AX1690
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.3
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots CPU:
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
* The PCIEX16 slot shares bandwidth with the M2C_CPU connector. The PCIEX16
slot operates at up to x8 mode when a device is installed in the M2C_CPU connector.
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
