Gigabyte B760 GAMING X [6/42] 2 box contents
![Gigabyte B760 GAMING X DDR4 [6/42] 2 box contents](/views2/1918722/page6/bg6.png)
- 6 -
1-2 Box Contents
5 B760 GAMING X AX, B760 GAMING X, B760 GAMING X AX DDR4, or
B760 GAMING X DDR4 motherboard
5 User's Manual
5 One antenna jl
5 Two SATA cables
5 M.2 screws
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
j Only for B760 GAMING X AX.
