- 17 -
Settings
& PEG ASPM
Allows you to congure the ASPM mode for the device connected to the CPU PEG bus.
& PCH ASPM
Allows you to congure the ASPM mode for the device connected to Chipset's PCI Express bus.
& DMI ASPM
Allows you to congure the ASPM mode for both CPU side and Chipset side of the DMI link.
& S3 Save Mode
Allows you to determine whether to let the system enter power-saving mode in system S3 state.
& ErP
Determines whether to let the system consume least power in S5 (shutdown) state.
Note: When this item is set to Enabled, the Resume by Alarm function becomes unavailable.
& Soft-Off by PWR-BTTN
Congures the way to turn off the computer in MS-DOS mode using the power button.
Instant-Off Press the power button and then the system will be turned off instantly.
Delay 4 Sec. Press and hold the power button for 4 seconds to turn off the system. If the power
button is pressed for less than 4 seconds, the system will enter suspend mode.
Platform Power
