18) BAT (Battery)

The battery provides power to keep the values (such as BIOS congurations, date, and time information)

in the CMOS when the computer is turned off. Replace the battery when the battery voltage drops to a low

level, or the CMOS values may not be accurate or may be lost.

You may clear the CMOS values by removing the battery:

1. Turn off your computer and unplug the power cord.

2. Gently remove the battery from the battery holder

and wait for one minute. (Or use a metal object like

a screwdriver to touch the positive and negative

terminals of the battery holder, making them short

for 5 seconds.)

3. Replace the battery.

4. Plug in the power cord and restart your computer.

• Always turn off your computer and unplug the power cord before replacing the battery.

• Replace the battery with an equivalent one. Damage to your devices may occur if the battery is replaced

with an incorrect model.

• Contact the place of purchase or local dealer if you are not able to replace the battery by yourself or uncertain

about the battery model.

• When installing the battery, note the orientation of the positive side (+) and the negative side (-) of the battery

(the positive side should face up).

• Used batteries must be handled in accordance with local environmental regulations.

19) RST (Reset Jumper)

The reset jumper can connect to the reset switch on the chassis front panel. Press the reset switch to

restart the computer if the computer freezes and fails to perform a normal restart.

The reset jumper provides you with several functions to use. To remap the button to perform different tasks,

please navigate to the "BIOS Setup" page of GIGABYTE's website and search for "RST_SW (MULTIKEY)" for

more information.

Pin No. Denition

1 Reset

2 GND

B760M AORUS PRO AX/B760M AORUS PRO

B760M AORUS PRO AX DDR4/B760M AORUS PRO DDR4

Pin No. Denition

1 Reset

2 GND
