Gigabyte B760M D2H Инструкция по эксплуатации онлайн
B760M D2H
B760M D2H DDR4
User's Manual
Rev. 1002
For more product details, please visit GIGABYTE's website.
https://www.gigabyte.com/Motherboard/B760M-D2H-rev-10?m=ma#kf
https://www.gigabyte.com/Motherboard/B760M-D2H-DDR4-rev-10?m=ma#kf
GIGABYTE will reduce paper use in order to fulll the responsibilities of a global citizen.
Also, to reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
Содержание
- B760m d2h b760m d2h ddr4 1
- Rev 1002 1
- User s manual 1
- Copyright 2
- Disclaimer 2
- Identifying your motherboard revision 2
- Chapter 1 product introduction 3
- Chapter 2 hardware installation 3
- Chapter 3 bios setup 9 3
- Chapter 4 installing the operating system and drivers 1 3
- Chapter 5 appendix 3 3
- Table of contents 3
- 1 motherboard layout 4
- B760m d2h 4
- Chapter 1 product introduction 4
- B760m d2h ddr4 5
- Temperature sensor 5
- 2 box contents 6
- 1 installation precautions 7
- Chapter 2 hardware installation 7
- 2 product specifications 8
- 2 productspecifications 8
- 3 installing the cpu and cpu cooler 11
- A note the cpu orientation 11
- B installing the cpu 12
- Do not force to engage the cpu socket locking lever when the cpu is not installed correctly as this would damage the cpu and cpu socket 12
- Follow the steps below to correctly install the cpu into the motherboard cpu socket 12
- Be sure to install the cpu cooler after installing the cpu actual installation process may differ depending the cpu cooler to be used refer to the user s manual for your cpu cooler 13
- C installing the cpu cooler 13
- 4 installing the memory 14
- Dualchannelmemoryconfiguration 14
- 5 installing an expansion card 15
- 6 back panel connectors 16
- D sub port 16
- Hdmi port 16
- Ps 2 keyboard mouse port 16
- Rj 45 lan port 16
- Usb 2 1 port 16
- Usb 2 1 port q flash plus port 16
- Usb 3 gen 1 port 16
- Audio jack configurations 17
- Line in rear speaker out blue 17
- Line out front speaker out green 17
- Mic in center subwoofer speaker out pink 17
- Please visit gigabyte s website for details on configuring the audio software 17
- The line in jack use this audio jack for line in devices such as an optical drive walkman etc 17
- The line out jack 17
- The mic in jack 17
- You can change the functionality of an audio jack using the audio software to configure 7 channel audio access the audio software for audio settings 17
- 7 onboard buttons and led 18
- 7 onboard buttons and leds 18
- Qflash_plus q flash plus button 18
- Quick butto 18
- 8 internal connectors 19
- 2 atx_12v_2x4 atx 2x4 12v power connector and 2x12 main power connector 20
- The 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 20
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 20
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation 20
- 4 cpu_fan sys_fan1 sys_fan2 fan headers 21
- All fan headers on this motherboard are 4 pin most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the speed control function requires the use of a fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis 21
- Be sure to connect fan cables to the fan headers to prevent your cpu and system from 21
- Connect your addressable led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 of the addressable led strip header incorrect connection may lead to the damage of the led strip 21
- Connector cpu_fan sys_fan1 sys_fan2 21
- D_led addressable led strip header 21
- Maximum current 2a 2a 2a 21
- Maximum power 24w 24w 24w 21
- No pin 21
- Overheating overheating may result in damage to the cpu or the system may hang 21
- Pin no definition 21
- Pwm speed control 21
- The header can be used to connect a standard 5050 addressable led strip with maximum power rating of 5a 5v and maximum number of 1000 leds 21
- These fan headers are not configuration jumper blocks do not place a jumper cap on the headers 21
- Voltage speed control 21
- Before installing the devices be sure to turn off the devices and your computer unplug the power cord from the power outlet to prevent damage to the devices 22
- Chipset supports raid 0 raid 1 raid 5 and raid 10 please navigate to the configuring a raid set page of gigabyte s website for instructions on configuring a raid array 22
- Connect your rgb led strip to the header the power pin marked with a triangle on the plug of the led strip must be connected to pin 1 12v of this header incorrect connection may lead to the damage of the led strip 22
- For how to turn on off the lights of the led strip please navigate to the unique features page of gigabyte s website 22
- Led_c rgb led strip header 22
- Sata3 4 5 6 7 sata 6gb s connectors 22
- The header can be used to connect a standard 5050 rgb led strip 12v g r b with maximum power rating of 2a 12v and maximum length of 2m 22
- The sata connectors conform to sata 6gb s standard and are compatible with sata 3gb s and sata 1 gb s standard each sata connector supports a single sata device the inte 22
- To enable hot plugging for the sata ports please navigate to the bios setup page of gigabyte s website and search for sata configuration for more information 22
- Follow the steps below to correctly install an m ssd in the m connector step 1 pull the clip s tab up and out of the mounting hole slide the m ssd into the connector at an angle step 2 press the m ssd down and then secure it by pressing the clip s tab into the mounting hole 23
- M pcie x4 ssd m pcie x2 ssd m sata ssd 23
- M2a_cpu a a 23
- M2a_cpu m2p_sb m socket 3 connectors 23
- M2p_sb a a 23
- The m connectors on the motherboard support only m pcie ssds 23
- Types of m ssds supported by each m connector 23
- F_panel front panel header 24
- 5vdual 25
- F_audio front panel audio header 25
- Head phone detection 25
- Head phone l 25
- Head phone r 25
- Mic detection 25
- No pin 25
- Pin no definition 25
- Sense_send 25
- Some chassis provide a front panel audio module that has separated connectors on each wire instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 25
- Spdif_o s pdif out header 25
- Spdifo 25
- The front panel audio header supports high definition audio hd you may connect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 25
- This header supports s pdif digital output which allows you to connect a s pdif digital audio cable to output digital audio from your motherboard to the supported audio devices for information about connecting the digital audio cable carefully read the manual for your audio devices 25
- D1 18 ssrx2 26
- D1 19 vbus 26
- F_u32 usb 3 gen 1 header 26
- F_usb1 f_usb2 f_usb3 usb 2 1 headers 26
- Gnd 14 sstx2 26
- Gnd 17 ssrx2 26
- Nc 20 no pin 26
- No pin 26
- Pin no definition 26
- Pin no definition pin no definition 26
- Power 5v 26
- Prior to installing the usb bracket be sure to turn off your computer and unplug the power cord from the power outlet to prevent damage to the usb bracket 26
- Ssrx1 12 d2 26
- Ssrx1 13 gnd 26
- Sstx1 15 sstx2 26
- Sstx1 16 gnd 26
- The header conforms to usb 3 gen 1 and usb 2 specification and can provide two usb ports for purchasing the optional 3 front panel that provides two usb 3 gen 1 ports please contact the local dealer 26
- The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 26
- Usb dx 26
- Usb dy 26
- Vbus 11 d2 26
- Chip select 27
- Com serial port header 27
- Data input 27
- Data output 27
- No pin 27
- Pin no definition 27
- Power 3 v 27
- Spi_tpm trusted platform module header 27
- The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 27
- You may connect an spi tpm trusted platform module to this header 27
- Clr_cmos clear cmos jumper 28
- Rst reset jumper 28
- Bat battery 29
- Chapter 3 bios setup 30
- Function keys 31
- Startup screen 31
- 1 operating system installation 32
- Chapter 4 installing the operating system and drivers 32
- 2 drivers installation 33
- 1 configuring a raid set 34
- 1 configuringaraidset 34
- Before you begin please prepare the following items 34
- Chapter 5 appendix 34
- Raid levels 34
- Regulatory notices 35
- United states of america federal communications commission statement 35
- Contact us 36
- Gigabyte esupport 36
- To submit a technical or non technical sales marketing question please link to https esupport gigabyte com 36
