Gigabyte B760M D2H [18/36] 7 onboard buttons and led

- 18 -

2-7 Onboard Buttons and LED

Quick Buttonk

The reset button (RST_SW) allows users to quickly turn on/off the computer in an open-case environment when

they want to change hardware components or conduct hardware testing.

QFLASH_PLUS (Q-Flash Plus Button)

Q-Flash Plus allows you to update the BIOS when your system is off (S5 shutdown state). Save the latest BIOS

on a USB thumb drive and plug it into the dedicated port, and then you can now ash the BIOS automatically by

simply pressing the Q-Flash Plus button. The QFLED will ash when the BIOS matching and ashing activities

start and will stop ashing when the main BIOS ashing is complete.

To enable the Q-Flash Plus function, please navigate to the "Unique Features" page of GIGABYTE's

website for more information.

The reset button provides you with several functions to use. To remap the button to perform different

tasks, please navigate to the "BIOS Setup" page of GIGABYTE's website and search for "RST_SW

(MULTIKEY)" for more information.

QFLASH_PLUS

QFLED

RST_SW

k Only for B760M D2H DDR4.
